25 SLCT 26 N.C.
2.16 Front Panel Connector (CN4)
Pin Signal Pin Signal
1 Power On Button (-) 2 Power On Button (+)
3 IDE LED (-) 4 IDE LED (+)
5 External Buzzer (-) 6 External Buzzer (+)
7 Power LED (-) 8 Power LED (+)
9 Reset Switch (-) 10 Reset Switch (+)
2.17 USB Port #1 and Port #2 (CN5)
Pin Signal Pin Signal
1 VDD 2 Ground
3 D0- 4 Ground
5 D0+ 6 D1+
7 Ground 8 D1-
9 Ground 10 VDD
2.18 Digital I/O Connector (CN6)
Pin Signal Pin Signal
1 Port 1 2 Port 2
3 Port 3 4 Port 4
5 Port 5 6 Port 6
7 Port 7 8 Port 8
9 +5Volt. 10 Ground
DIO Address is 801H
BIOS Setting Connector
Definition
Address IT8712 GPIO Setting
DIO-1 CN6 Pin 1 Bit 7 U1 Pin 20 (GPIO 27)
