S u b C o m p a c t B o a r d G E N E - 5 3 1 5
Chapter 2 Quick Installation Guide 2 - 21
29 A2 +5V
30 A1 OSC
31 A0 GND
32 GND GND
J2/P2
Pin D C
1 GND GND
2 MEMCS16* SBHE*
3 IOCS16* LA23
4 IRQ10 LA22
5 IRQ11 LA21
6 IRQ12 LA20
7 IRQ15 LA19
8 IRQ14 LA18
9 DACK0* LA17
10 DRQ0 MEMR*
11 DACK5* MEMW*
12 DRQ5 SD8
13 DACK6* SD9
14 DRQ6 SD10
15 DACK7* SD11
16 DRQ7 SD12
17 +5V SD13
18 MASTER* SD14
19 GND SD15
20 GND GND/KEY
Note 1: GENE-5315 does not support PC/104 way legacy ISA-DMA
mode caused by AMD architecture.
Note 2: Allocation Method of PC/104 Card for GENE-5315
PC/104 connector on GENE-5315 cannot automatically get
“Resource” when a new PC/104 card is added because of AMD
