S u b C o m p a c t B o a r d G E N E - 5 3 1 5
Chapter 2 Quick Installation Guide 2 - 16
7 Ground 8 INDEX#
9 Ground 10 MTRA#
11 Ground 12 DRVB#
13 Ground 14 DRVA#
15 Ground 16 MTRB#
17 Ground 18 DIR#
19 Ground 20 STEP#
21 Ground 22 WDATA#
23 Ground 24 WGATE#
25 Ground 26 TRK0#
27 Ground 28 WPT#
29 N.C. 30 RDATA#
31 Ground 32 HDSEL#
33 N.C. 34 DSKCHG#
2.15 Parallel Port (CN3)
Pin Signal Pin Signal
1 STB# 2 AFD#
3 PTD0 4 ERR#
5 PTD1 6 PINIT#
7 PTD2 8 SLIN#
9 PTD3 10 Ground
11 PTD4 12 Ground
13 PTD5 14 Ground
15 PTD6 16 Ground
17 PTD7 18 Ground
19 ACK# 20 Ground
21 BUSY 22 Ground
23 PE 24 Ground
