S u b C o m p a c t B o a r d G E N E - 5 3 1 5
Chapter 2 Quick Installation Guide 2 - 25
2 +5 Volt.
3 Ground
2.27 Ethernet 10/100 Base-TX RJ-45 Phone Jack #1 (CN15)
Pin Signal Pin Signal
1 RXD- 2 RXD+
3 RCT 4 N.C.
5 N.C. 6 TCT
7 TXD- 8 TXD+
9 ACT_LED 10 LINK_LED
11 +3.3 Volt. 12 SPD_LED
13 Ground 14 Ground
2.28 Ethernet 10/100 Base-TX RJ-45 Phone Jack #2 (CN16)
Pin Signal Pin Signal
1 RXD- 2 RXD+
3 RCT 4 N.C.
5 N.C. 6 TCT
7 TXD- 8 TXD+
9 ACT_LED 10 LINK_LED
11 +3.3 Volt. 12 SPD_LED
13 Ground 14 Ground
2.29 IrDA Connector (CN17)
Pin Signal
1 +5 Volt.
2 CIR_TX (Option)
3 RX
