Technical Data
610.44444.40.000 8 / 36 © Gardner Denver Deutschland GmbH
3 Technical Data
3.1 Mechanical data
Weight
Weight
(when not filled with water)
Type approx. [kg] approx. [lbs]
2BL2 041 38 83.8
2BL2 061 55 121
2BL2 101 68 150
2BL2 141 105 232
2BL2 251 195 430
2BL2 281 210 463
2BL2 341 225 496
Weight
(when filled with water)
Type approx. [kg] approx. [lbs]
2BL2 041 61 134
2BL2 061 97 214
2BL2 101 110 243
2BL2 141 161 355
2BL2 251 290 640
2BL2 281 305 673
2BL2 341 320 706
Filling capacity of separator
Filling capacity for operating
liquid
Type
max.
[l]
max.
[gal(US)]
max.
[gal(UK)]
2BL2 041 23 6.08 5.06
2BL2 061 42 11.1 9.24
2BL2 101 42 11.1 9.24
2BL2 141 56 14.8 12.3
2BL2 251 94 24.8 20.7
2BL2 281 94 24.8 20.7
2BL2 341 94 24.8 20.7
(Normal tap water should usually be used as
operating liquid.)
Filling capacity for antiliming
agent
Type approx. [kg] approx. [lbs]
2BL2 041 2 4.41
2BL2 061 4 8.82
2BL2 101 4 8.82
2BL2 141 5 11
2BL2 251 8 17.6
2BL2 281 8 17.6
2BL2 341 8 17.6
(Use pure granulated citric acid as antiliming
agent. The specified filling quantities for citric acid
refer to the medium filling of the separator with
operating liquid.)
Filling quantity of installed unit
Filling quantity for anti-corrosive
agent
Type [l] [gal (US)] [gal (UK)]
2BL2 041 0.6 0.159 0.132
2BL2 061 1.0 0.264 0.220
2BL2 101 1.0 0.264 0.220
2BL2 141 1.0 0.264 0.220
2BL2 251 5.5 1.453 1.210
2BL2 281 6.3 1.664 1.386
2BL2 341 7.0 1.849 1.540
(To ensure sufficient protection, the entire interior
of the installed unit must be filled with anti-
corrosive agent. Use only anti-corrosive agent
based on ethylene glycol without additives, e.g.
Antifrogen from Hoechst!)
Filling quantity for antiliming
liquid
Type [l] [gal (US)] [gal (UK)]
2BL2 041 0.6 0.159 0.132
2BL2 061 1.0 0.264 0.220
2BL2 101 1.0 0.264 0.220
2BL2 141 1.0 0.264 0.220
2BL2 251 5.5 1.453 1.210
2BL2 281 6.3 1.664 1.386
2BL2 341 7.0 1.849 1.540
(Use 10 % ethanoic acid as antiliming liquid.)
