Set up and operation
A
O
I K U
P P
1
Q
M
K
1
Q
H
1
U
7
I
1
U
2
U
4
H
4 Set up and operation
4.1 Setup
A Vacuum connection
H, H
1
Oil fi lling point
I, I
1
Oil sight glass
K, K
1
Oil discharge point
M Oil recommendation plate
O Rotation direction plate
P Drive motor
P
1
Motor data plate
Q hot surfaces > 70°C
U
2
Temperature control
U
4
Liquid level monitor
U
7
Thermostatic water valve (option)
Fig. 2 Vacuum pump S-VSI 300 (42)
S-VSI 300 (42)
