ITEM
1
2
3
4
5
6
7
8
9
10
11
12
QTY
1
1
1
1
1
1
1
1
1
1
1
1
PART NO.
16107
16684
14273
8353
8225
14272
8265
1353
8226
12094
17633*
8243
MATERIAL
302 SST
SST
Bronze
Aluminum
Brass
302 SST
Brass
Steel
Steel
Brass
Buna-N
®
Brass
DESCRIPTION
Adjusting Screw
Lock Nut
Spring Chamber
Name Plate
Spring Button
Pressure Spring
Pusher Post Button
Nut
Washer
Pressure Plate
Diaphragm
Diaphragm Stop
LIST OF MATERIALS
ITEM
13
13a
13b
13c
13d
13e
13f
13g
14
15
16
17
QTY
1
1
1
2
1
1
1
1
1
1
1
1
PART NO.
17744
9288*
17634
8273*
8664*
17635
17638*
17637*
17636
9162
8274
MATERIAL
Buna-N ®
303 SST
Buna-N
®
Buna-N ®
303 SST
Brass
Buna-N
®
Brass-Forged
302 SST
Brass
DESCRIPTION
Piston Sub Assy.
O-ring
Cylinder
O-ring
O-ring
Pusher Post
Piston
Seat Disc
Body
Piston Spring
Bottom Plug
* Recommended spare part (kit). Note: Lubricate O-ring #9288 before re-assembly pilot with a kit.
When Ordering, Please Specify
1. Adjustment Range Desired
Specification
Size 3/8" NPT screwed
Temperature Range Water: 180˚F Max.
Materials
Body & Cover: Cast Bronze ASTM B-62
Trim: Brass & Stainless Steel 303
Rubber: Buna-N ® (Fabric Reinforced)
Max. Inlet PSI 720 psi
Adjustment Range
psi: 200/400 - Cla-Val #R803707
Mounting Positions
Multi-poise
(operates in any position)
Weight 3lbs
Repair Kit Cla-Val #R2000202J
CLA - VAL
copyright Cla-Val 2003 Printed in USA Specifications subject to change without notice.
P.O. Box 1325 • Newport Beach, CA 92659-0325 • Phone: 949-722-4800 • Fax: 949-548-5441 • E-mail: [email protected] • Website cla-val.com
©
PL-RCRDHP (R- 5/05 )
#19165
