B
CLEAN OUT CONNECTION
FLOW
A
N.P.T. BOTH ENDS
(SEE LISTING)
1-13/16
FREE FLOW
1-3/32 DIA
7/16 AF HEX
(BOTH ENDS)
BIB FOR 1/4 I.D.
FLEXIBLE TUBING
OR HOSE
(BOTH ENDS)
1-13/16
FREE FLOW
1-3/32 DIA.
7/16 AF HEX
(BOTH ENDS)
1/4 O.D.
COMPRESSION
CONNECTION
(BOTH ENDS)
RX43Y
2 Way Strainers
General Description
Forged Brass, Bronze, Cast Iron and Stainless Steel Bodies. These rugged self-
cleaning "Y" type body strainers have an easily removable strainer element of
perforated stainless steel sheet or wire mesh in cylindrical form. The total free
hole area as specified in the table is the total area of all perforations or openings
through the straining elements. They are suitable for air, water, oil and steam.
Plastic Body. These strainers have a straight through flow design with a large
area orifice. The strainer can be easily removed from the line and cleaned by
back flushing. They are suitable for air and water.
Applications
Strainers should be used wherever it is essential that the fluid flowing through
pipe lines be maintained free of foreign solid matter. This is necessary to assure
proper flow and to prevent damage to controls and other equipment.
Installation
The strainers may be mounted in any position. When installed with solenoid
valves, the strainer should be connected in the upstream (inlet) side of the valve
—as close to the valve as possible.
SPECIFICATIONS
DIMENSIONS (in inches)
Pipe
Size
(ins.)
CV
Flow
Factor
Screen
Mesh
Size
1/8
1/4
3/8
1/2
3/4
0.5
0.5
0.5
0.5
1.0
1.7
1.9
2.6
4.7
80x80
80x80
80x80
80x80
60x60
60x60
100x100
100x100
100x100
Total
Free
Hole
Area
(in. 2 )
.116
.116
.116
.116
.325
.325
.35
.50
.75
Particle
Retention
Size
Blow-off
Pipe
Size
(ins.)
-
-
-
-
-
-
-
-
-
Maximum
Fluid
Temp.
˚F.
130
130
130
130
400
400
400
400
400
Safe
Working
Pressure
(psi)
50
175
50
175
750
750
750
750
750
Catalog
Number
86044
86042
86045
86043
8600A1
8600A2
8600A13
8600A14
8600A15
Microns
178
178
178
178
155
155
155
155
155
Inches
.007
.007
.007
.007
.0061
.0061
.0061
.0061
.0061
Con.
Ref
No.
1
1
3
3
2
2
2
2
2
Dimensions
(ins.)
A B
1 11/32
1 11/32
1 5/8
1 13/16
2 3/32
2
2
1 29/32
2 9/32
2 3/4
1
1 1/4
1 1/2
2
20
27
40
70 40x40
40x40
40x40
40x40 3.83
4.98
6.95
7.05 3/4
3/4
3/4
1
150
150
150
150 500
500
500
500 8600B6
8600B7
8600B8
8600B9 510
510
510
510 .015
.015
.015
.015 2
2
2
2 3 1/2
4 3/16
4 3/4
5 11/16
4 7/8
5 3/8
6 3/8
7 1/2
3/8
1/2 2.1
3.0 60x60
60x60 .23
.35 1/4
1/4 450
450 1500
1500 86014
86015 250
250 .0098
.0098 2
2 1 27/32
2
1 29/32
2 9/32
1/4
3/8
1/2
3/4
1
1 1/4
1 1/2
2
2 1/2
2.0
3.5
6.5
12
20
27
40
70
90
40x40
40x40
40x40
40x40
40x40
40x40
40x40
40x40
40x40 1.01
1.01
1.62
2.94
3.83
4.98
6.95
7.05
10.88
1/4
1/4
3/8
1/2
3/4
1
1 1/4
1 1/2
1 1/4
150
150
150
150
150
150
150
150
150 300
300
300
300
300
300
300
300
300 8602B12
8602B13
8602B14
8602B15
8602B16
8602B17
8602B18
8602B19
8602B20 510
510
510
510
510
510
510
510
510 .015
.015
.015
.015
.015
.015
.015
.015
.015 2
2
2
2
2
2
2
2
2 2 3/16
2 3/16
2 11/16
3 3/8
3 1/2
4 3/16
4 1/2
5 7/16
6 3/4
2 7/8
2 7/8
3 7/16
4 3/8
4 7/8
5 3/8
6 3/8
7 1/2
8 5/8
Acetal Body with Stainless Steel Strainer Element and Buna "N" Seals
Forged Brass Body with Stainless Steel Strainer Element and Teflon* or Viton* Seals
Bronze Body with Stainless Steel Strainer Element
Cast Iron Body with Stainless Steel Strainer Element
Stainless Steel Body with Stainless Steel Strainer Element and Teflon* Seals
1
1 5
4
4 5
2
2
2
2
2
2
2
2
7 8
7 8
7
7
7
1/4" O.D. compression connection. Fittings are not sup-
plied.
See Dimensions.
Other mesh sizes may be available; consult factory.
Bibs for 1/4" I.D. flexible tubing or hose.
Where pressure exceeds 50 psi, it is advisable to use
hose or tubing clamps.
Metal body strainers are rated for steam at 250 psi
maximum pressure and 406˚F. maximum temperature.
UL recognized component.
Valve supplied with Viton seal.
* DuPont Co. trademark
1
2
3
4
5
6
7
8
ORDERING INFORMATION
IMPORTANT:
We must have PIPE SIZE and CATALOG NO.
3
3
6 6
8
Con.
Ref. 1
Con.
Ref. 3
Con.
Ref. 2
INSTALLATION / OPERATION / MAINTENANCE
MODEL
CLA - VAL
