3650-02 is the reduced internal port size version of the 350-02.
For 100-01 basic valves, suggested flow calculations were based on flow through Schedule 40 Pipe. Maximum continuous flow is approx. 20 ft/sec (6.1 meters/sec) & maximum
intermittent is approx. 25 ft/sec (7.6 meters/sec) and minimum continuous flow is approx. 1 ft/sec (.3 meters/sec). For 100-20 basic valves, suggested flow calculations were
based on flow through the valve seat. Approx. 26 ft/sec (7.9 meters/sec) was used for maximum continuous flow & 1 ft/sec (.3 meters/sec) is used for minimum continuous
flow.
** Flanged End Detail Only
When Ordering, Please Specify
1. Catalog No. 350-02 or 3650-02 6. Trim Material
2. Valve Size 7. Adjustment Range
3. Pattern - Globe or Angle 8. Desired Options
4. Pressure Class 9. When Vertically
5. Threaded or Flanged Installed
PO Box 1325 Newport Beach CA 92659-0325
Phone: 949-722-4800 Fax: 949-548-5441
CLA-VAL
CLA-VAL CANADA CLA-VAL EUROPE
4687 Christie Drive
Beamsville, Ontario
Canada L0R 1B4
Phone: 905-563-4963
Fax: 905-563-4040 Chemin dés Mesanges 1
CH-1032 Romanel/
Lausanne, Switzerland
Phone: 41-21-643-15-55
Fax: 41-21-643-15-50
© COPYRIGHT CLA-VAL 2009 Printed in USA
Specifications subject to change without notice. www.cla-val.com E-350-02/3650-02 (R-6/09)
Represented By:
Adjustment Ranges
0 to 75 psi
20 to 105 psi
20 to 200 psi
End Connection
1/2" NPT
Temperature Range
Water: to 180°F
Materials
Pilot Control: Bronze ASTM B62
Trim:Stainless Steel Type 303
Rubber:Buna-N
® Synthetic Rubber
Available with optional Stainless Steel or Monel
materials at additional cost. Consult factory for details
Pilot Control Subassembly Specifications
Electronic Actuator Specifications
Valve Selection
These Symbols
A
and
B
Indicate Available Sizes
Inches 1 1 ⁄
4
1 1 ⁄
2
2 2 1 ⁄
2
3 4 6 8 10 12 14 16 18 20 24 30 36 42 48
mm 32 40 50 65 80 100 150 200 250 300 350 400 450 500 600 800 900 1000 1200
End Detail Threaded Threaded & Flanged Flanged
Model
350-02
Basic Valve
100-01
Globe
A A A A A A A A A A A A A A A A
Angle
B B B B B B B B B B B B
Suggested Flow
(gpm)
Max. Continuous 93 125 210 300 460 800 1800 3100 4900 7000 8400 11000 17000 25000
Max. Intermittent 120 160 260 370 580 990 2250 3900 6150 8720 10540 13700 21700 31300
Min. Continuous 10 10 15 20 30 50 115 200 300 400 500 650 900 1750
Suggested Flow
(Liters/Sec)
Max. Continuous 6 8 13 19 29 50 113 195 309 442 530 694 1073 1577
Max. Intermittent 7.6 10 16 23 37 62 142 246 387 549 664 863 1369 1972
Min. Continuous .6 .6 .9 1.3 1.9 3.2 7.2 13 19 25 32 41 57 110
Consult Factory for Sizes Not Shown
Model
3650-02
Basic Valve
100-20
Globe A
**
A A A A A A A A A A A A A A
Angle B B B
Suggested Flow
(gpm)
Max. Continuous 260 580 1025 2300 4100 6400 9230 9230 16500 16500 16500
Min. Continuous 15 30 50 115 200 300 500 500 900 900 900
Suggested Flow
(Liters/Sec)
Max. Continuous 16 37 65 145 258 403 581 581 1040 1040 1040
Min. Continuous .9 1.9 3.2 7.2 13 19 32 32 57 57 57
Supply Power Input: 12V to 24V DC24V DC
No Load draw: 50 mA
Max. Load draw: 250 mA
Remote Command Inputs: •
4-20mA, analog signal
(optically-isolated and reverse-polarity
protected)
• Dry contact closure (CW/CCW)
Position Feedback Signal: 4-20 mA
Alarm Output:
Dry-contact closure (High/Low)
Speed of Rotation: Adjustable On/Off time, max 6 rpm
Diagnostic: LED Indicator
Loss of Power: Actuator will remain in last commanded
position.
Loss of Signal Position: Programmable - 4 mA, Last, or 20 mA
Electrical Connections: Single, 30 feet of permanently attached
cable with color-coded power supply
and signal wires
Mechanical Specifications:
Environmental
Protection Class: IP-68 (Temporary submersible)
Ambient Temperature: 15° to 150° F (-10° to 65° C)
Materials
Enclosure and Bracket: Anodized Aluminum
Coupling Assembly: Stainless Steel
Gear Train: Stainless Steel, permanently lubricated
