4" Through 24" Sizes
1/2"Through 3" Sizes
0
1
2
3
4
5
0 2 4 6 8 10 14 18 22 30 40 26
1/2" 1" 2" 3"
PRESSURE IN P
.S.I.
AIR FLOW DISCHARGE CAPACITY IN CUBIC FEET OF FREE AIR/SEC.
25 0 50 75 100 125 150 200 250 300 350 400 450 500 550 600 650 700 750
0
1
2
3
4
5
4" 6" 8" 10" 12" 14" 16"
PRESSURE IN P
.S.I.
AIR FLOW DISCHARGE CAPACITY IN CUBIC FEET OF FREE AIR/SEC.
8" through 16" available with flanged outlet in place of hood.
AND SIZING GUIDE
Series 35
CLA - VAL
' copyright Cla-Val 2003 Printed in USA Specifications subject to change without notice.
P.O. Box 1325 ¥ Newport Beach, CA 92659-0325 ¥ Phone: 949-722-4800 ¥ Fax: 949-548-5441 ¥ E-mail: [email protected] ¥ Website cla-val.co
E-35 (R-5/00)
For sizes 18” and larger consult factory.
Model No.
350-AV.3
351-AV.3
352-AV.3
353-AV.3
Inlet Size
1/2” NPT
1" NPT
2" NPT
3" NPT
Outlet Size
1/2" NPT
1" NPT
2" NPT
3" NPT
Max. W.P.
300 PSI
300 PSI
300 PSI
300 PSI
Height
7"
9 1/2"
12"
12"
Width
6 1/8"
7"
9 1/2"
9 1/2"
Wt.Lbs
15
26
48
50
Model No.
354-AV
354-AV.3
356-AV
356-AV.3
358-AV
358-AV.3
3510-AV
3510-AV.3
3512-AV
3512-AV.3
3514-AV
3514-AV.3
3516-AV
3516-AV.3
4" FLG-125lb
4" FLG-250lb
6" FLG-125lb
6" FLG-250lb
8" FLG-125lb
8" FLG-250lb
10" FLG-125lb
10" FLG-250lb
12" FLG-125lb
12" FLG-250lb
14" FLG-125lb
14" FLG-250lb
16" FLG-125lb
16" FLG-250lb
4"
4"
6"
6"
8"
8"
10"
10"
12"
12"
14"
14"
16"
16"
200 PSI
500 PSI
200 PSI
500 PSI
200 PSI
500 PSI
200 PSI
500 PSI
200 PSI
500 PSI
200 PSI
500 PSI
200 PSI
500 PSI 17"
17"
20"
20"
23"
23"
26"
26"
31"
31"
34"
34"
34"
34" 12"
12"
14"
14"
18"
18"
20"
20"
24"
24"
27"
27"
30 1/2"
30 1/2"
105
115
160
175
208
255
370
400
590
640
681
740
879
930
Inlet Size/
Class
Outlet Size Max. W.P. Height Width Wt.Lbs
Chart A
Chart B
When Ordering,
Please Specify:
1. Model Number
2. Inlet Size (NPT)
3. Inlet Pressure Rating
4. Orifice Size
5. If Operating Pressure
Below 20 PSI
