Pump Solutions Group Neptune Series 6000 dia-PUMP MODELS 6100 thru 6250 User Manual
Page 17
17
PARTS LIST FOR PUMP MODELS 6100 to 6250
(REFER TO PART DRAWING ON PAGE 16)
PARTS FOR PUMPS WITH METAL HEADS
ITEM#
DESCRIPTION
QTY.
SST - PART NO.
C20 - PART NO.
55
Discharge Valve Cap
1
002073
002072
57
Anti-Siphon Spring
1
100198
100199
58
Discharge Valve Nut
1
000215
000216
59
Discharge Cartridge
1
000209
000210
61
Suction Valve Cartridge
1
000217
000218
62
Liquid Head
1
004104
004106
63
Suction Valve Cap
1
000207
000208
64
Diaphragm Back Up Plate, Liquid Side
1
000195
000196
ITEM#
DESCRIPTION
QTY.
PART#
1
Gear Box
1
004089
2
Thrust Washers
4
107595
3
Worm Gear 58 SPM
1
004098
Worm Gear 117 SPM
1
004099
4
Eccentric
1
004100
5
Gear Shaft
1
107598
6
Shaft Retainer O-Ring
1
107580
7
Gear Shaft Retainer Screws
7
100211
8
Gear Shaft Retainer
1
004094
9
3/8” Lock Washers
4
100217
10
3/8-16 X 1" lg. screws
4
100216
11
Wave Spring
1
107599
12
Fill/Vent Plug
1
000191
13
Oil Seal
1
106586
14
Motor Adapter O-Ring
1
107600
15
Ball Bearing
1
106180
16
Worm Shaft 58 SPM
1
004096
Worm Shaft 117 SPM
1
004103
17
Motor Coupling Key
1
106589
18
Woodruff Key
1
107601
19
Worm Shaft Bushing
1
107736
20
Bearing Cone
1
107596
21
Bearing Cup
1
107597
22
Worm 58 SPM
1
107592
Worm 117 SPM
1
107593
23
Spring Pin
2
100010
24
Gasket
1
107581
25
Motor Adapter
1
004095
26
Connecting Rod
1
004091
27
Connecting Rod Pin
1
100304
28
Connecting Rod Sleeve
1
000359
29
Pump Body 3/4” Dia.
1
004109
Pump Body 1” Dia.
1
004110
ITEM# DESCRIPTION
QTY. PART#
30
Piston 3/4” Dia.
1
004231
Piston 1” Dia.
1
004232
31
1/8 NPT Pipe Plug
1
100196
32
Relief Valve Cap
1
000365
33
Relief Valve Cap O-Ring
1
100200
34
Relief Valve Adjusting Screw
1
000364
35
Relief Valve Spring
1
100310
36
Relief Valve Ball Guide
1
000379
37
1/4" Dia. Ball
1
100559
38
Sealing Plate 3/4” & 1” pistons
1
004111
39
Sealing Nut
1
004102
40
Knob Friction O-Ring
1
100327
41
Pump/Head Screws
4
105081
42
Control Rod Screw
1
004093
43
Control Knob Screw
1
100308
44
Control Knob
1
004092
45
Indicator Plate Screws
2
100190
46
Indicator Plate
1
000188
47
Teflon Diaphragm
1
004108
48
Oil Side Back-up Plate
1
000194
49
Control Rod Spring Pin
1
100063
50
Control Rod O-Ring
1
100323
51
Control Rod Parbak Rings
2
106547
52
Sealing Plate O-Ring
1
100082
53
Control Rod, for 3/4” or 1” Piston
1
000385
54
Air Bleed Plug
1
100210
56
Valve Cap O-Rings
2
100200
60
Valve Seat O-Rings
2
100204
65
Pump Head Screws
8
107575
66
Washers
8
107577
67
Drain Plug
1
100300
68
Sealing Plate backup Ring
1
108019
