16
15.0.2 RECOMMENDED SPARE PARTS:
IMPORTANT: When ordering spare parts, please show MODEL NUMBER AND SERIAL NUMBER of pump for which
parts are being ordered. This information can be found on a stainless steel nameplate riveted to the side of the pump.
Recommended Spare Parts (for metal head “dia-PUMP”). It is recommended that the following parts be kept in stock
for a pump:
Kit #002719 - Fits all Kit NO.002720 - Fits all
FIG. # DESCRIPTION “N1/N3" Models "N4" Models
Qty Part NO. Qty Part NO.
516-C Sealing Plate "0" Ring 2 100186 2 100186
2310 Teflon Diaphragm 1 000388 1 000388
2334 Control Rod "0" Ring 2 100323 2 100323
2337 Vent Plug "0" Ring 2 100325 2 100325
2340 Valve Ball (316SS) or 4 100078 -
Valve Ball (C-20) - 4 100079
2342 Valve Seat 0" Ring 8 100327 8 100327
2343 Discharge & Suction cap "0" Ring 4 100328 4 100328
5695 Valve Seat (316SS) or 4 002831 -
Valve Seat (C-20) 4 002832
15.0.3 RECOMMENDED SPARE PARTS FOR PVC and KYNAR HEAD "dia-PUMP"
Pump Serial Number > or = 147995
See PVC and Kynar Head Option on Page 20
Kit #004384 for PVC
Head
Kit #004385 for KYNAR
Head FIG. # DESCRIPTION
Part # Qty. Part # Qty.
5 (Page#20) Teflon Diaphragm 000388 1 000388 1
2 (Page#20) Check Valve Assembly 004165 2 004166 2
516-C (Page#18) Sealing Plate "0" Ring 100186 2 100186 2
2334 (Page#18) Control Rod "0" Ring 100323 2 100323 2
Recommended Spare Parts (for PVC head "dia-PUMP). OLD STYLE (BEFORE JUNE 2004)
Pump Serial Number < or = 147994
FIG. # DESCRIPTION Kit #002721 - Fits all "N5" OLD Models
Qty Part #.
516-C Sealing Plate .0" Ring 2 100186
2310 Teflon Diaphragm 1 000388
2334 Control Rod .0" Ring 2 100323
5624 Vent Plug "0" Ring 2 100322
5628 Discharge & Suction cap “0" Ring 4 100274
5629 Vent Plug “0" Ring 2 100272
5630 Valve Seat “0" Ring 4 100273
5649 Valve Ball Ceramic 2 100275
PARTS ORDERING INSTRUCTIONS
Note: For prompt entry of parts orders: your order must include both model and serial numbers.
