* Silicone Sealant may be substituted for Gasket “N” indicates parts per new version
Valve stacks of all Series 560 (except PVC models) have been improved by the attention of close tolerance ball guides which
allow for better accuracy and higher pressure performance.
Improved stack arrangements are shown in the figures on page #15.
Parts are currently furnished only for the improved version. When ordering replacement seats for an original valve stack
design, order the ball guides (FIG. #5691) and spacer (FIG. #5693). Installing these parts and discarding the old spacers (FIG.
#2320 and FIG. #2326) will upgrade the pump to the Improved valve arrangement. (Refer to the drawing on page#15)
If seats are not replaced, it is not necessary to change the spacers and ball guides. If seats are replaced (the new seals are of a
different thickness) the ball guides and spacers must be replaced.
SECTION VI
PARTS LIST
14.0 PARTS LIST FOR STANDARD SERIES 560 "DIA-PUMP" WITH METAL PUMP HEAD (REFER TO DRAWING #5670)
FIG.
NO.
DESCRIPTION QTY. PART
NO.
501 Worm Gear 37 SPM* 1 000164
Worm Gear 72 SPM* 1 000166
Worm Gear 117 SPM* 1 000163
Worm Gear 144 SPM* 1 002818
502 Connecting Rod 1 000167
506 Worm 37 SPM 1 000170
Worm 72 SPM 1 000172
Worm 117 SPM 1 000169
Worm 144 SPM 1 002817
507 Bearing Cup 1 100179
508 Bearing Cone 1 100180
509 Worm Spring Pin 1 100181
510 Drain Plug 1 100182
511 Connecting Rod Pin 1 100183
512 Fill Plug 1 002827
516-
C Sealing Plate O-Ring 1 100186
519 Control Rod Spring Pin 1 100189
520 Indicator Plate 1 000188
521 Indicator Plate Screws 2 100190
522 Control Knob Set Screw 1 100191
523 Control Rod Positioner 1 000189
524 Control Knob Assembly 1 002071
525 Capacity Indicator Scale 1 100192
526 Sealing Nut 1 002069
530 Relief Valve Plug 1 100196
534 Pump Body Cap Screws 4 100197
551 Screw 5/16 x 1 1/4” lg. (N1) 8 100205
Screw 5/16 x 1” lg. (N3, N4) 8 100206
557
Hydraulic Fluid (2 qts.)
ISO68
1 003089
590 Gasket or Sealer 1 106290
2309
Pump Body Side Backup
Plate 1
000387
2310 Teflon Diaphragm 1 000388
2330
Pump Head Back Up Plate
(N1, N3)
1 000406
Pump Head Back Up Plate
(N4) 1
000407
2334 Control Rod O-Ring 1 100323
2337 Vent Plug O-Ring 1 100325
2340 Valve Balls (N1, N3) 4 100078
Valve Balls (N4) 4 100079
2342 Valve Seat O-Ring 4 100327
FIG.
NO.
DESCRIPTION QTY
.
PART
NO.
2343 Discharge & Suction Cap O-Rings 2 100328
5002 Shaft Retainer Assembly* 1 002722
5004 Thrust Washers 3-4 100252
5025 Shaft Retainer Screws 3 100254
5601 Gear Box 1 000296
5602 Sealing Plate 1 000307
5604 Vent Plug (N1, N3) 1 000308
Vent Plug (N4) 1 000309
5606 Suction Spacer (N1, N3) 1 000310
Suction Spacer (N4) 1 000311
5608 Discharge Spacer (N1, N3) 1 000312
Discharge Spacer (N4) 1 000313
5610 Discharge Cap (N1, N3) 1 000303
Discharge Cap (N4) 1 000304
5612 Suction Cap (N1, N3) 1 000301
Suction Cap (N4) 1 000302
5614 Piston 2” 1 000314
5615 Control Rod 1 000315
5648 Relief Valve Ball 1 100201
5650 Relief Valve Spring 1/3 & 1/2 HP 1 100276
Relief Valve Spring 3/4 & 1 HP 1 106428
5651 Relief Valve Plug 1 100332
5652 Relief Valve Adjusting Screw 1 100277
5660 Pump Head (N1) 1 000298
Pump Head (N3) 1 000299
Pump Head (N4) 1 000300
5663 Pump Body R.H. 1 000297
5666 Anti-Siphon Spring (N1, N3) 1 000340
Anti-Siphon Spring (N4) 1 000341
5668-
A Std. Motor Assembly 37 SPM** 1 002404
Std. Motor Assembly 72 SPM** 1 002405
Std. Motor Assembly 117 SPM** 1 002406
5691 Ball Guide (N1, N3) 3 001260
Ball Guide (N4) 3 001261
5693 Stack Spacer (N1, N3) 1 002828
Stack Spacer (N4) 1 002829
5695 Valve Seat (N1, N3) 4 002831
Valve Seat (N4) 4 002832
5697 Gasket or Sealer* Oil Head 1 106292
5699 Sealing Nut O-Ring 1 100417
** Includes Part Nos. 506, 508 and 509. 1/2-1-115-60-TEFC-CAP-48Y.
