Series Components:
LTD 5 Series
LT5-2 SS 5" x 5" Strainer Only with Satin Stainless Finish
LT5-2 PS 5" x 5" Strainer Only with Polished Stainless Finish
CDI 22 Clamp Down Drain Cast Iron
CDA 22 Clamp Down Drain ABS
CDP 22 Clamp Down Drain PVC
WW 5 Series
W5-2 SS 5" x 5" Wedge Wire Strainer - Satin Stainless Finish
W5-2 PS 5" x 5" Wedge Wire Strainer - Polished Stainless Finish
CDI 22 Clamp Down Drain Cast Iron
CDA 22 Clamp Down Drain ABS
CDP 22 Clamp Down Drain PVC
LW 5 Series
L5-2 SS 5" x 5" Strainer Only - Satin Stainless Finish
L5-2 PS 5" x 5" Strainer Only - Polished Stainless Finish
L5-2 ORB 5" x 5" Strainer Only - Lifetime Oil Rubbed Bronze Finish
CDI 22 Clamp Down Drain Cast Iron
CDA 22 Clamp Down Drain ABS
CDP 22 Clamp Down Drain PVC
RTD 15 Series
RT 15A 5" Round Tile Drain Strainer
CDI 42 4" Throat x 2" Outlet Clamp Down Drain Cast Iron
CDI 43 4" Throat x 3" Outlet Clamp Down Drain Cast Iron
CDA 42 4" Throat x 2" Outlet Clamp Down Drain ABS
CDA 43 4" Throat x 3" Outlet Clamp Down Drain ABS
CDP 42 4" Throat x 2" Outlet Clamp Down Drain PVC
CDP 43 4" Throat x 3" Outlet Clamp Down Drain PVC
TD 15 Series
T15 A SS 5" x 5" Strainer Only - Satin Stainless Finish
T15 A PS 5" x 5" Strainer Only - Polished Stainless Finish
CDI 42 4" Throat x 2" Outlet Clamp Down Drain Cast Iron
CDI 43 4" Throat x 3" Outlet Clamp Down Drain Cast Iron
CDA 42 4" Throat x 2" Outlet Clamp Down Drain ABS
CDA 43 4" Throat x 3" Outlet Clamp Down Drain ABS
CDP 42 4" Throat x 2" Outlet Clamp Down Drain PVC
CDP 43 4" Throat x 3" Outlet Clamp Down Drain PVC
TKEY Lift Out Key
HS 4 4" Hair Strainer Stainless Steel Throat
TD 20 Series
T20 A SS 8" x 8" Strainer Only - Satin Stainless Finish
T20 A PS 8" x 8" Strainer Only - Polished Stainless Finish
CDI 42 4" Throat x 2" Outlet Clamp Down Drain Cast Iron
CDI 43 4" Throat x 3" Outlet Clamp Down Drain Cast Iron
CDA 42 4" Throat x 2" Outlet Clamp Down Drain ABS
CDA 43 4" Throat x 3" Outlet Clamp Down Drain ABS
CDP 42 4" Throat x 2" Outlet Clamp Down Drain PVC
CDP 43 4" Throat x 3" Outlet Clamp Down Drain PVC
TKEY Lift Out Key
HS 4 4" Hair Strainer
G Series Components (Each sold separately)
G 1 Herring Strainer
G 2 Line Strainer
G 3 Square Strainer
G 4 Otto Strainer
T 2 Residential 5" x 5" Stainless Steel 2” Throat
T 4 High Flow 5" x 5" Stainless Steel 4” Throat
MG 5 5" x 5" Mud Guard
Optional Components: (Not Included)
UCP 2 Universal 2" Clamping Plate
UCP 4 Universal 4" Clamping Plate
ERB Eccentric Reducing Bushing 4"x2"
Note: Installer must verify all rough-in
dimensions prior to installation and consult
local and national codes. Conformity and
compliance to local and national codes are
the responsibility of the installer.
Tenga en cuenta: Instalador debe
comprobar todas las dimensiones en las
partes previa a la instalación y consultar
localmente y nacionalmente los códigos. La
conformidad y el cumplimiento de códigos
local y nacional es responsabilidad del
instalador.
