FIXED FLANGE (FF) SERES
Subfloor
Stainless Steel
Channel
Waste Line
Rubber Coupling
Mortar Bed
Liquid/Fabric
Waterproofing
Finishing Material
Backer Board
Thinset
Finished Grate
SIDE OUTLET (FT) SERIES
Subfloor
Stainless Steel
Channel
Rubber Coupling
Mortar Bed
Liquid/Fabric
Waterproofing
Finishing Material
Backer Board
Thinset
Finished Grate
