Installation and Operation, cont’d
2-6 YCS SW2 A • Installation and Operation 2-7
3
1 2
OUT PUT
INPU TS MLS 103 V L R
A B
L R L R L R 1 2 3 L R 4 AUX/M IX MON O
AUD IO IN PUT S
PRE AM P MLC /RS-2 32 POW ER 12V .5A M AX
3
1 2
OUT PUT
INPU TS MLS 103 V L R
A B
L R L R L R 1 2 3 L R 4 AUX/M IX MON O
AUD IO IN PUT S
PRE AM P MLC /RS-2 32 POW ER 12V .5 A M AX
3
1 2
OUT PUT
INPU TS MLS 103 V L R
A B
L R L R L R 1 2 3 L R 4 AUX/M IX MON O
AUD IO IN PUT S
PRE AM P MLC /RS-2 32 POW ER 12V .5A M AX
MM X 32 VG A A
OU TPU T 1 2
1
3
OU TPU T 2 2
1
3
Y C S S W 2
2
1
A U TO S W IT C H
Back of the Rack Mounting Kit
Figure 2-5 — Mounting the YCS SW2 A to a back of
the rack support
Furniture mounting
To furniture-mount the YCS SW2 A, use the optional VersaTools
mini under-desk mounting kit (part #70-212-01), as follows:
1
. If rubber feet were previously attached to the bottom of the
unit, remove them.
2 . Remove the two screws from one side of the YCS. Retain
the screws for possible later reassembly.
3 . Attach one bracket to the side of the unit, using the
provided machine screws (see figure 2-6, below).
QuarterRackUnderdeskMounting
Figure 2-6 — Preparing the YCS SW2 A for under-
desk mounting
Back of the rack mounting
The YCS SW2 A can also be mounted vertically to the front or
rear rack supports, using the optional MBB 100 back of the rack
mounting kit (part #70-367-01).
Follow these steps to mount the YCS to the rack supports using
the back of the rack mounting kit:
1
. If feet were previously attached to the bottom of the YCS,
remove them.
2 . Remove the two screws from one side of the YCS. Retain
the screws for possible later reassembly.
3 . Attach one bracket to the side of the unit, using the longer
screws included in the mounting kit (see figure 2-4, below).
BackofRackMountingEars
Figure 2-4 — Attaching the back of the rack
mounting brackets to the YCS SW2 A
4 . Repeat steps 2 and 3 on the other side of the YCS.
5 . Mount the unit to the rack support, using the two included
rack screws.
