Operation, cont’d

SW AV Series Switchers • Operation

3-2

Operation

Front Panel Controls and Indicators

The family of SW AV switchers have a wide variety of input buttons and other
controls and LEDs that vary with the number of inputs and whether the switcher
has video, audio, or both. Not all switchers have every control or indicator
described in this chapter. The table at the bottom of this page identifies the control
and indicator groups that are present on each switcher in the SW AV Series.

In the following descriptions, you will find the following terms:

Video switcher

— Switches composite video or S-video. May or may not

include audio switching.

Video-only switcher

— Switches composite video or S-video only. No audio

switching.
