A-5 SW RGBHV Series Switchers • Specifications and Part Numbers
Part Numbers
SW RGBHV switcher part numbers
Switcher Part #
SW2 RGBHV video switcher 60-491-01
SW2 RGBHV A video and audio switcher 60-491-21
SW4 RGBHV video switcher 60-492-01
SW4 RGBHV A video and audio switcher 60-492-21
SW6 RGBHV video switcher 60-493-01
SW6 RGBHV A video and audio switcher 60-493-21
Supplied accessories
Switcher Part #
SW RGBHV switcher User’s Manual
Universal Switcher Control Program
MBD 149 1U through-desk and rack mounting kit
(SW4 and SW6 models only)
70-077-03
3.5 mm 5-pole captive screw connectors; 2, 4, or 6
(audio models only)
10-319-10
Optional accessories
Extron Part Part #
SW2 models only
RSU 129 1U universal rack shelf kit
60-190-01
RSB 129 1U basic rack shelf 60-604-02
MBU 125 under-desk mount kit 70-077-01
MBD 129 through-desk mount kit 70-077-02
SW4 and 6 models only
MBU 149 under desk mount kit
70-222-01
All models
KP 6 keypad remote control
60-111-20
IR 102 infrared remote control kit 70-224-01
SVHSM-BNCF adapter 26-353-01
Cables
When using signals with a scanning frequency of 15-125 kHz and running distances
of 100 feet or more, use RG6 or Mini HR BNC cables for best performance. Rental
and staging (RC) cable is ideal for jobs with repeated installation and removal in
high traffic areas.
Bulk cables
RG6 super high resolution cable Part #
RG6-5/500, five conductor, non-plenum, 500' (150 m) 22-100-02
RG6/500, one conductor, non-plenum, 500' (150 m) 22-098-02
RG6/1000, one conductor, non-plenum, 1000' (300 m)' 22-098-03
RG6P/500, one conductor, plenum, 500' (150 m) 22-164-02
RG6P/1000, one conductor, plenum, 1000' (300 m)' 22-164-03
