Specifications, cont’d
SW RGBHV Series Switchers • Specifications and Part Numbers A-4
Contact closure pin configurations 1 = input #1, 4 = input #2, 6 = input #3, 7 = input #4, 8 = input #5,
9 = input #6
Program control ........................... Extron’s control/configuration program for Windows ®
Extron’s Simple Instruction Set (SIS ™ )
General
Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 20 watts, internal
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, non-condensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, non-condensing
Cooling .......................................... Convection, no vents
Rack mount
SW2 RGBHV, SW2 RGBHV A
Yes, with optional 1U, 9.5" deep rack shelf,
part #60-190-01 (RSU 129) or 60-604-02 (RSB 129). Also, furniture mountable
with optional MBU 125 under-desk mounting kit (part #70-077-01).
All other models .............. Yes, with included mounting kit, part #70-077-03 (MBD 149). Also, furniture
mountable with optional MBU 149 1U under-desk mounting kit
(part #70-222-01).
Enclosure type .............................. Metal
Enclosure dimensions
SW2 RGBHV, SW2 RGBHV A
1.75" H x 8.75" W x 9.5" D (1U high, half rack wide)
(4.4 cm H x 22.2 cm W x 24.1 cm D)
(Depth excludes connectors.)
All other models .............. 1.75" H x 17.5" W x 8.5" D (1U high, full rack wide)
(4.4 cm H x 44.5 cm W x 21.6 cm D)
(Depth excludes connectors.)
Product weight
SW2 RGBHV ..................... 2.4 lbs (1.1 kg)
SW2 RGBHV A ................ 2.5 lbs (1.1 kg)
All other models .............. 7.0 lbs (3.2 kg)
Shipping weight
SW2 RGBHV, SW2 RGBHV A
5 lbs (3kg)
All other models .............. 12 lbs (6 kg)
Vibration ....................................... ISTA 1A in carton (International Safe Transit Association)
Listings .......................................... UL, CUL
Regulatory compliance
Safety ................................. CE, C-tick, CUL, UL
EMI/EMC ......................... CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
Specifications are subject to change without notice.
