SW2 VGAcc and SW2 RGBHVcc • Reference Information

SW2 VGAcc and SW2 RGBHVcc • Reference Information

Specifications, Part Numbers, Accessories, cont’d

A-5

Cables

Male-to-Male BNC Cables

Part number

BNC-5 3’ MHR

26-260-15

BNC-5 6’ MHR

26-260-01

BNC-5 12’ MHR

26-260-02

BNC-5 25’ MHR

26-260-03

Male-to-Male VGA Cables

Part number

VGA 3’ MHR

26-238-14

VGA 6’ MHR

26-238-01

VGA 10’ MHR

26-238-07

VGA 15’ MHR

26-238-02

Accessories

Accessories

Part number

1U Universal Rack Shelf

60-190-01

1U Basic Rack Shelf

60-604-01

1U 6" Deep Universal Rack Shelf Kit

60-190-10

1U 6" Deep Basic Rack Shelf

60-604-10

Under-desk Mounting Kit

70-077-01

Through-desk Mounting Kit

70-077-02

Mac HV/VGA adapter

26-340-02

SY-VGA/Male to 5 BNC female adaptor

26-531-01

Switchers

Models

Part number

SW2 VGAcc

60-679-01

SW2 RGBHVcc

60-680-01

Included Parts

Included Parts

IEC power cord

Tweeker

SW2 VGAcc and SW2 RGBHVcc User’s Manual

3.5 mm, 5-pole captive screw connector

Rubber feet (4)

A-4

Enclosure dimensions ................. 1.7" H x 8.7" W x 6.0" D (1U high, half rack

wide)
4.3 cm H x 22.1 cm W x 15.2 cm D
(Depth excludes connectors.)

Product weight ............................. 2 lbs (1 kg)
Shipping weight .......................... 4 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton (International Safe

Transit Association)

Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor

All nominal levels are at ±10%

Specifications are subject to change without notice.
