SW2 VGAcc and SW2 RGBHVcc • Reference Information

SW2 VGAcc and SW2 RGBHVcc • Reference Information

Specifications, Part Numbers, and Accessories

A-3

Nominal level ............................... 1 Vp-p for Y of component video and S-

video, and for composite video
0.7 Vp-p for RGB
0.3 Vp-p for R-Y and B-Y of component
video, and for C of S-video

Minimum/maximum levels ...... 0.3 V to 1.5 Vp-p (follows input)
Impedance .................................... 75 ohms
Return loss .................................... <-43 dB @ 5 MHz
DC offset ....................................... ±5 mV with input at 0 offset

Sync

Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB, RsGsBs (follows

input)

Input level ..................................... Analog or TTL, 1.7 V to 5.0 Vp-p
Output level .................................. 5.0 Vp-p, unterminated
Input impedance .......................... 510 ohms
Output impedance ....................... 50 ohms
Max. propagation delay ............. 30 ns
Max. rise/fall time ....................... 4 ns
Polarity .......................................... Positive or negative (follows input)

Control/remote — switcher

Contact closure/tally .................. (1) 3.5 mm captive screw connector, 5 pole
Contact closure and tally pin configurations

1 = input 1 contact closure, 2 = input 2
contact closure, 3 = GND,
4 = input 1 tally output, 5 = input 2 tally
output

General

Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 7 watts,

internal, autoswitchable

Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /

10% to 90%, noncondensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, noncondensing

Rack mount ................................... Yes, with optional 1U rack shelf,

part #60-190-01, 60-190-10, 60-604-01,
or 60-604-10
Also furniture mountable with an optional
Under-desk Mounting kit, #70-077-01

Enclosure type .............................. Metal

A-2

Specifications

Video

Gain ............................................... Unity
Bandwidth .................................... 350 MHz (-3 dB)
Crosstalk ....................................... <-68dB @ 10 MHz
Switching speed ........................... 5 ms (max.)

Video input

Number/signal type

SW2 VGAcc ...................... 2 VGA–UXGA RGBHV, RGBS, RGsB,

RsGsBs computer video

SW2 RGBHVcc ................. 2 RGBHV, RGBS, RGsB, RsGsBs,

component video, S-video, composite
video

Connectors

SW2 VGAcc ...................... 2 female 15-pin HD
SW2 RGBHVcc ................. 2 x 5 female BNC

Nominal level ............................... 1 Vp-p for Y of component video and S-

video, and for composite video
0.7 Vp-p for RGB
0.3 Vp-p for R-Y and B-Y of component
video, and for C of S-video

Minimum/maximum levels ...... Analog: 0.3 V to 1.5 Vp-p with no offset
Impedance .................................... 75 ohms
Horizontal frequency .................. 15 kHz to 145 kHz
Vertical frequency ....................... 30 Hz to 179 Hz
Return loss .................................... <-42 dB @ 5 MHz
DC offset (max. allowable) ......... 1.7 V

Video output

Number/signal type

SW2 VGAcc ...................... 1 VGA–UXGA RGBHV, RGBS, RGsB,

RsGsBs computer video

SW2 RGBHVcc ................. 1 RGBHV, RGBS, RGsB, RsGsBs,

component video, S-video, composite
video, (follows input type)

Connectors

SW2 VGAcc ...................... 1 female 15-pin HD
SW2 RGBHVcc ................. 5 female BNC
