Wallplates • Specifications, Part #s, Dimensions
Wallplates • Specifications, Part #s, Dimensions
A-3
Included Parts
These items are included in each order for a wallplate:
Included parts
Part number
WP 120
(gray, black, white, unfinished)
60-431-01, -11, -21, -51
WP 120
(gray, black, white, unfinished)
60-431-02, -12, -22, -52
WP 120 AUS
(white)
60-431-32
WP 130
(gray, black, white, unfinished)
60-430-01, -11, -21, -51
WP 130
(gray, black, white, unfinished)
60-430-02, -12, -22, -52
WP 150
(gray, black, white, unfinished)
60-427-01, -11, -21, -51
WP 150
(gray, black, white, unfinished)
60-427-02, -12, -22, -52
WP 150 AUS
(white)
60-427-32
WP 170
(gray, black, white, unfinished)
60-429-01, -11, -21, -51
WP 170
(gray, black, white, unfinished)
60-429-02, -12, -22, -52
WP 170 AUS
(white)
60-429-32
WP 180
(gray, black, white, unfinished)
60-428-01, -11, -21, -51
WP 180
(gray, black, white, unfinished)
60-428-02, -12, -22, -52
WP Wallplates User’s Manual
68-606-01
The part number of each model of the wallplates varies
(60-4xx-x1 or 60-4xx-02) depending on the date of
manufacture. There is no functional difference between
the -x1 and -x2 versions.
The dimensions diagrams in this manual show the
60-4xx-x2 wallplates.
or
or
or
or
or
or
or
or
or
Specifications, Part Numbers, Dimensions
A-2
Specifications
General
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Rack mount ................................... No, but furniture/wall mountable.
Enclosure type .............................. Metal
Dimensions
1-gang models
Faceplate ................... 4.5" H x 2.8" W x 0.1" D (11.4 cm H x 7.1
cm W x 0.3 cm D) (1 gang)
Boards ........................ 2.6" H x 1.75" W x 1.1" D (6.6 cm H x 4.4
cm W x 2.8 cm D)
(Depth includes rear connectors. Allow at
least 2.5" (6.4 cm) depth within the wall
box or furniture to accommodate the
circuit board, connectors, and cables.)
AUS models
Faceplate ................... 3.0" H x 4.7" W x 0.1" D (7.6 cm H x 11.8
cm W x 0.3 cm D)
Boards ........................ 1.75" H x 2.6" W x 1.1" D (4.4 cm H x 6.6
cm W x 2.8 cm D)
(Depth includes rear connectors. Allow at
least 2.5" (6.4 cm) depth within the wall
box or furniture to accommodate the
circuit board, connectors, and cables.)
Product weight ............................. 0.2 lbs (0.1 kg)
Shipping weight ........................... 1 lbs (1 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. FCC Class A, VCCI, AS/NZS, ICES as
components of the MLC 206
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
