RGB 470xi xi xi xi xi Series • Specifications and Parts
Specifications and Parts, cont’d
RGB 470xi xi xi xi xi Series • Specifications and Parts A-5 A-4
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non condensing
Rack mount ................................... No
RGB 472/474/478 xi SC-AFM models
Steel City AFM floor box mountable
RGB 472 xi FSR models .... FSR floor box mountable
All other models .............. Wall or furniture mountable
Enclosure type .............................. Metal
Enclosure dimensions
RGB 472 xi faceplate .......... 4.5” H x 4.6” W x 0.1" D (2 gang)
(11.4 cm H x 11.7 cm W x 0.3 cm D)
RGB 474 xi, 478 M xi faceplate
4.5” H x 6.4” W x 0.1" D (3 gang)
(11.4 cm H x 16.3 cm W x 0.3 cm D)
RGB 478 xi faceplate .......... 4.5” H x 8.3” W x 0.1" D (4 gang)
(11.4 cm H x 21.2 cm W x 0.3 cm D)
RGB 472 xi EC faceplate ... 3.2" H x 4.4" W x 0.1" D
(8.0 cm H x 11.2 cm W x 0.3 cm D)
RGB 478 xi EC faceplate ... 3.2" H x 7.7" W x 0.1" D
(8.0 cm H x 19.5 cm W x 0.3 cm D)
RGB 472 xi FSR faceplate . 4.5" H x 3.6" W x 0.1" D
(11.4 cm H x 9.1 cm W x 0.3 cm D)
RGB 472 xi SC-AFM2 faceplate
2.9" H x 3.5" W x 0.1” D
(7.4 cm H x 8.9 cm W x 0.3 cm D)
RGB 472 xi SC-AFM4 faceplate
2.9" H x 5.8" W x 0.1” D
(7.4 cm H x 14.7 cm W x 0.3 cm D)
RGB 474 xi SC-AFM6, RGB 478xi SC-AFM6 faceplate
2.9" H x 8.9" W x 0.1” D
(7.4 cm H x 22.6 cm W x 0.3 cm D)
Interface enclosure for all models
2.7" H x 3.3" W x 1.2" D
(6.9 cm H x 8.4 cm W x 2.5 cm D)
(Depth excludes front panel connectors
and controls.)
Product weight
RGB 472xi SC-AFM2 ........ 0.5 lbs (0.3 kg)
RGB 472xi SC-AFM4,
RGB 474xi SC-AFM6,
RGB 478xi SC-AFM6 ........ 0.8 lbs (0.4 kg)
RGB 472 xi , RGB 472 xi FSR 0.5 lbs (0.2 kg)
RGB 474 xi .............................. 0.6 lbs (0.3 kg)
RGB 478 xi , RGB 478 M xi .. 0.7 lbs (0.3 kg)
EC models ......................... 0.7 lbs (0.3 kg)
Shipping weight (all models) ..... 3 lbs (1.4 kg)
Vibration ....................................... ISTA/NSTA 1A in carton (International
Safe Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
Specifications are subject to change without notice.
