Setup Guide — VTG 400D/400 DVI
68-786-50
Rev. A
03 09
4
Stereographics
Rates
Super Hi Res
Rates
16:9 Hi Res
Rates
Supported
Formats
Pixel x
Line
Horiz
Rate
(kHz)
Vert
Rate
(Hz)
Output Type
Supported
Formats
Pixel x
Line
Horiz
Rate
(kHz)
Vert
Rate
(Hz)
Output Type
Stereographics VGA
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
SGI stereo
640 x 222
640 x 480
640 x 512
1024 x 768
1024 x 768
1120 x 840
1280 x 1024
1280 x 1024
1280 x 492
31.5
60.84
65.28
96.84
77.47
84.38
124.60
131.16
63.96
120
120
120
120
96
96
114
120
120
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB
RGB
RGB, DVI
16:9
16:9
16:9
16:9
16:9
WXGA1
WXGA2
WXGA3
WXGA4
WXGA5
WXGA6
WXGA7
WXGA8
WSXGA
WSXGA+1
WSXGA+2
1080p PC
WUXGA1
WUXGA2
WQXGA
848 x 480
852 x 480
960 x 540
1024 x 576
1024 x 576
1280 x 768
1280 x 768
1280 x 768
1280 x 800
1360 x 765
1360 x 768
1365 x 768
1366 x 768
1440 x 900
1680 x 1050
1680 x 1050
1920 x 1080
1920 x 1200
1920 x 1200
2560 x 1600
31.02
31.8
33.78
44.04
52.85
45.11
48.0
47.77
49.7
47.7
47.72
47.7
47.8
55.94
64.67
65.29
67.2
74.52
74.6
99.46
60
60
60
60
72
56
60
60
60
60
60
60
60
60
60
60
60
60
60
60
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB, DVI
RGB
RGB, DVI
RGB
RGB
PC Rates
VGA
640 x 480
31.5
60
RGB, DVI
VESA 2 (VGA)
640 x 480
37.9
72
RGB, DVI
VESA1 (SVGA)
800 x 600
35.2
56
RGB, DVI
VESA5 (SVGA)
800 x 600
37.9
60
RGB, DVI
VESA6 (SVGA)
800 x 600
48.1
72
RGB, DVI
VESA3 (XGA)
1024 x 768
48.4
60
RGB, DVI
VESA4 (XGA)
1024 x 768
56.4
70
RGB, DVI
XGA5
1024 x 768
57
70
RGB, DVI
VESA8 (XGA)
1024 x 768
60
75
RGB, DVI
VESA9 (XGA)
1024 x 768
68.7
85
RGB, DVI
VESA10 (XGA+)
1152 x 864
67.5
75
RGB, DVI
1280 x 960
1280 x 960
60
60
RGB, DVI
1280 x 960
1280 x 960
70
70
RGB, DVI
1280 x 960
1280 x 960
75
75
RGB, DVI
VESA11 (SXGA)
1280 x 1024
64
60
RGB, DVI
VESA12 (SXGA)
1280 x 1024
91.1
85
RGB, DVI
SXGA+1
1400 x 1050
63.9
60
RGB, DVI
SXGA+2
1400 x 1050
65.32
60
RGB, DVI
VESA13 (UXGA)
1600 x 1200
75
60
RGB, DVI
VESA14 (UXGA)
1600 x 1200
87.5
70
RGB
VESA15 (UXGA)
1600 x 1200
106.3
85
RGB
QXGA1
2048 x 1536
99.46
60
RGB
QXGA2
2048 x 1536
115
71.8
RGB
LCoS1
1360 x 1024
80
75.1
RGB, DVI
LCoS2
1365 x 1024
65.2
60
RGB, DVI
Workstation
Rates
SGI
640 x 480
31.5
60
RGB, DVI
SGI
640 x 512
32.22
60
RGB, DVI
SGI
800 x 600
37.8
60
RGB, DVI
SGI
960 x 680
42.84
60
RGB, DVI
SGI
960 x 620
39.06
60
RGB, DVI
SGI
1024 x 768
48.36
60
RGB, DVI
SGI
1024 x 768
40.3
50
RGB, DVI
SGI
1200 x 900
68.04
72
RGB, DVI
SGI
1280 x 1024
53.25
50
RGB, DVI
SGI
1280 x 1024
63.9
60
RGB, DVI
SGI
1280 x 1024
76.68
72
RGB, DVI
SGI
1500 x 1200
75.6
60
RGB, DVI
SGI
1600 x 1024
63.38
60
RGB, DVI
SGI
1600 x 1200
75
60
RGB, DVI
SGI
1760 x 1100
71.04
60
RGB
SGI
1920 x 1035
33.75
60/30
RGB, DVI
SGI
1920 x 1080
33.72
60/30
RGB, DVI
SGI
1920 x 1080
70.31
60
RGB
SGI
1920 x 1080
84.37
72
RGB
SGI
1920 x 1200
77.52
60
RGB
SGI
1920 x 1200
85.27
66
RGB
SGI
2048 x 1120
83.45
72
RGB
Sun
1152 x 900
61.8
66
RGB, DVI
Sun
1152 x 900
71.7
76
RGB, DVI
Sun
1280 x 1024
81
76
RGB, DVI
Sun
1600 x 1280
89.3
67
RGB
Sun
1920 x 1080
84.4
72
RGB
Sun
1920 x 1200
87.2
70
RGB
Sun
1920 x 1200
93.6
75
RGB
HDTV
Rates
480p
576p
720p
720p
720p
720p
720p
720p
1080i
1080i
1080i
1080p
1080p
1080p
1080p
1080p
1080p
1080p (24PsF)
1080p (24PsF)
1035i
1035i
720 x 483
720 x 576
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1280 x 720
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1080
1920 x 1035
1920 x 1035
31.42
31.25
44.96
45
37.5
22.5
22.48
18.75
33.72
33.75
28.13
67.5
33.75
33.72
56.25
28.13
27
27
26.97
33.75
33.72
59.94
50
59.94
60
50
29.97
30
25
29.97
30
25
60
30
29.97
50
25
24
24
23.98
30
29.97
YUV, RGB, DVI
YUV, RGB, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
YUV, RGB, HDSDI, DVI
Video
Rates
NTSC
NTSC 0 IRE (JPN)
PAL I
PAL B, G, H
PAL N
720 x 485
720 x 485
720 x 575
720 x 575
720 x 575
15.7
15.7
15.6
15.6
15.6
60/30
60/30
50/25
50/25
50/25
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
VID, Y/C, YUV, RGB, SDI
Cornerstone
1600 x 1800
105
76
RGB
Extron
1280 x 1024
92
86.8
RGB, DVI
Extron
1600 x 1280
95
70.9
RGB
Extron
1800 x 1440
105
70
RGB
