Sync — PowerCage MTP T 15HD RSA, PowerCage MTP R 15HD RSA SEQ
Input/output type ........................... RGBHV, RGBS, RGsB, RsGsBs
Standards ....................................... NTSC 3.58, NTSC 4.43, PAL, SECAM
Input level (transmitter) .................. 3.5 V to 5.5 Vp-p, unterminated
Output level (receiver) .................... 4.0 V to 5.0 Vp-p, unterminated
Input impedance (transmitter) ........ 573 ohms ±5%
Output impedance (receiver) .......... 110 ohms
Polarity
Transmitter .............................. Positive or negative (follows input polarity)
Receiver ................................... Positive or negative (switch-selectable)
Audio — PowerCage MTP T 15HD RSA, PowerCage MTP R 15HD RSA SEQ
Number/signal type ........................ 1 set of proprietary analog signals
Connector ...................................... 1 female RJ-45
Gain ............................................... Unbalanced output: 0 dB; balanced output: +6 dB
Frequency response ........................ 20 Hz to 20 kHz, ±1 dB
THD + Noise ................................... 0.15% @ 1 kHz, 0.3% @ 20 kHz at nominal level
S/N ................................................. >70 dB at maximum output (unweighted)
Stereo channel separation .............. >60 dB @ 1 kHz
CMRR ............................................ >43 dB @ 20 Hz to 20 kHz
Audio input — PowerCage MTP T 15HD RSA
Number/signal type ........................ 1 stereo, unbalanced
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... >10k ohms, unbalanced
Nominal levels ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +18 dBu, (unbalanced) at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output — PowerCage MTP R 15HD RSA SEQ
Number/signal type ........................ 1 mono, balanced/unbalanced
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±1 dB channel to channel
Nominal levels ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +18 dBu, unbalanced at 1% THD+N
Control/Remote
Serial ports
Boards ..................................... Pass-through, uni- or bidirectional Input/output: 1 set of proprietary signals on female
RJ-45 jack
Output/input: 1 RS-232 via 3 poles of a 3.5 mm captive screw connector (3 pole for
transmitter, 5 pole for receiver)
Baud rate and protocol
Boards
Baud rates.......................... Up to 38400 bps at up to 600 ft (185 m). Higher data rates and distances are possible.
Performance varies based on baud rate and cable length.)
Protocol ............................. Data bits = 5 - 8
Stop bits = 1 or 2
Parity = odd, even, none
Flow control = XON, XOFF, none
Defaults: 8 data bits, 1 stop bit, no parity
NOTE: For PowerCage MTP boards, protocol is mirrored between the transmitter and the receiver.
Serial control pin configurations
Captive screw connector
Boards ............................... Transmitter: 1 = Tx, 2 = Rx, 3 = GND
Receiver: 3 = GND, 4 = Tx, 5 = Rx
Mini stereo jack ....................... RS-232: tip = Tx, ring = Rx, sleeve = GND
