Reference
Information
This section provides the specifications and part numbers for the
PowerCage MTP T 15HD RSA and MTP R 15HD RSA SEQ modular boards.
• Specifications
• Part Numbers
Specifications
Video — PowerCage MTP T 15HD RSA, PowerCage MTP R 15HD RSA SEQ
Gain ............................................... Unity
Number/signal type ........................ 1 set of proprietary analog signals
Connector ...................................... 1 female RJ-45
Video input — PowerCage MTP T 15HD RSA
Number/signal type ........................ 1 analog RGBHV, RGBS, RGsB, RsGsBs, component video (YUVi or YUVp/HDTV),
S-video, or composite video
Connector ...................................... 1 female 15-pin HD
Nominal levels ................................ 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.45 Vp-p
Impedance ..................................... 75 ohms
Horizontal frequency ...................... 15 kHz to 130 kHz
Vertical frequency ........................... 30 Hz to 150 Hz
Return loss ..................................... <-30 dB @ 5 MHz
DC offset (max. allowable) ............. 250 mV
Video output — PowerCage MTP R 15HD RSA SEQ
Number/signal type ........................ 1 analog VGA-UXGA RGBHV, RGBS, RGsB, RsGsBs,
component video (YUVi or YUVp/HDTV), S-video, or composite video
Connector ...................................... 1 female 15-pin HD
Nominal levels ................................ 1 Vp-p for Y of component video and S-video, and for composite video
0.7 Vp-p for RGB and for R-Y and B-Y of component video
0.3 Vp-p for C of S-video
Minimum/maximum levels .............. 0.3 V to 1.45 Vp-p
Impedance ..................................... 75 ohms
Return loss ..................................... <-30 dB @ 5 MHz
DC offset ....................................... <±25 mV with input at 0 offset
Skew compensation ....................... 62 ns
Maximum resolution ...................... Up to 1920x1200 or 2048x1080 or 1080p at 300 ft
Up to 1024x768 at 600 ft
NOTE: Refer to page 7 in this guide for maximum distances recommended for specific resolutions .
12 PowerCage MTP T 15HD RSA and PowerCage MTP R 15HD RSA SEQ • Reference Information
