Features
• PowerCage MTP T AV transmits composite video or S-video along with summed mono
audio signals 1,000 feet (300 meters) or more over a single CAT 5, 5e, 6, or Extron
Enhanced Skew-Free
™ UTP cable.
• Compatible with NTSC, PAL, and SECAM
• Modular, field-upgradeable, and hot-swappable boards are designed for the PowerCage
1600 enclosure. The compact design of the enclosure accommodates up to 16 single-
slot or 8 double-slot boards, eliminates the need for individual power supplies for each
transmitter and receiver, and provides forced-air cooling for each module.
• Hot-swappable components allow the user to replace boards or install additional
transmitter and receiver boards any time for quick and easy upgradeability or expansion
without the need to power down the system. . This is especially useful for mission-
critical applications that require continuous system operation.
• LED power indicator.
• Compatible with MTP Series video receivers, and MTP Series switchers, matrix switchers,
and distribution amplifiers.
• PowerCage MTP R AV receives composite video or S-video along with summed mono
audio signals 1,000 feet (300 meters) or more over a single CAT 5, 5e, 6, or Extron
Enhanced Skew-Free
™ UTP cable.
• Sharpness and gain controls for optimizing signal and image quality
PowerCage MTP T AV and PowerCage MTP R AV • Introduction 2
