Audio input — PowerCage MTP T AV
Number/signal type ........................ 1 stereo, unbalanced
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... >10k ohms, unbalanced: >20k ohms, balanced: AC coupled
Nominal levels ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +18 dBu, (unbalanced) at 1% THD+N
NOTE: 0 dBu = 0.775 Vrms, 0 dBV = 1 Vrms, 0 dBV ≈ 2 dBu
Audio output — PowerCage MTP R AV
Number/signal type
MTP R AV ................................ 2 mono, balanced/unbalanced
Connector ...................................... (1) 3.5 mm captive screw connector, 5 pole
Impedance ..................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±1 dB channel to channel
Nominal levels ................................ +4 dBu (1.23 Vrms), -10 dBV (316 mVrms)
Maximum level ............................... +18 dBu, unbalanced at 1% THD+N
General
Recommended cable type .............. Extron Enhanced Skew-Free ™ A/V UTP cable, CAT 5/5e/6 (shielded or unshielded)
Power consumption ....................... Each MTP board at 115 VAC, 60 Hz
MTP T AV: 2.69 watts
MTP R AV: 3.92 watts
Power input requirements ............. 12 VDC, 1.0 A, supplied by the PowerCage enclosure
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
Cooling .......................................... Boards: convection, within the PowerCage enclosure
Enclosure type ................................ Metal
Enclosure dimensions
Boards ..................................... Fits a single slot opening in a PowerCage enclosure.
Product weight
Boards ..................................... 0.8 lbs (0.4 kg)
Shipping weight
Boards ..................................... 2 lbs (1 kg) each
Vibration ........................................ ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ...................................... CE, c-UL, UL
EMI/EMC ................................. CE, C-tick, FCC Class A, ICES, VCCI
MTBF ............................................. 30,000 hours
Warranty ........................................ 3 years parts and labor
NOTES: All nominal levels are at ±10%.
Specifications are subject to change without notice.
PowerCage MTP T AV and PowerCage MTP R AV • Reference Information 9
