RGB 324/326/340 • Specifications , Accessories, & Part Numbers RGB 324/326/340 • Specifications , Accessories, & Part Numbers
Specifications , Accessories & Part Numbers, cont’d
Video
Gain ............................................... Unity (0.7V p-p), (0.8V p-p) 15% with 3dB
peaking, (0.9V p-p) 30% with 6dB peaking
Bandwidth .................................... 300 MHz (-3dB)
Video input
Number/signal type ................... 1 analog RGBHV, RGBS, RGsB, RsGsBs
Connectors .................................... 1 9-pin D male analog for
MBC/LBC cable
Nominal level(s) .......................... Analog ....... 0.3V to 1.45V p-p
Impedance .................................... 75 ohms or Hi Z, switchable (set to
75 ohms if no local monitor is connected)
Horizontal frequency .................. 15 kHz to 100 kHz (optimum 15 kHz to
62 kHz)
Vertical frequency ....................... 30 Hz to *170 Hz
Video output
Number/signal type ................... 1 analog RGBHV, RGBS, RGsB, RsGsBs
Connectors .................................... 5 BNC female
Nominal level ............................... Analog ....... 0.7V p-p, 0.8V p-p, 0.9V p-p
(internal jumper-selectable)
with peaking
Impedance .................................... 75 ohms
Return loss .................................... -48dB @ 5 MHz
Sync
Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB, RsGsBs; TTL
buffered to RGB 320 control unit
Input level ..................................... 3.0V to 5.0V p-p (referenced to ground)
Output level .................................. 4.0V to 5.0V p-p
Input impedance .......................... 10 kohms
Output impedance ....................... 75 ohms
Max propagation delay ............... 45 nS
Max. rise/fall time ....................... 3.9 nS
Polarity .......................................... Positive, negative
Audio — buffered to RGB 320
Gain ............................................... Unbalanced 0dB, balanced +6dB
Frequency response ..................... 20 Hz to 20 kHz, ±0.05dB
THD + Noise ................................ 0.03% @ 1 kHz, 0.3% @ 20 kHz at rated
maximum output drive
S/N ................................................ >90dB, output 17dBu, balanced
Stereo channel separation ........... >95dB @ 1 kHz to 20 kHz
Audio input — buffered to RGB 320
Number/signal type ................... 1 stereo, unbalanced; 1.0Vrms (+4dBu),
20 Hz to 20 kHz
Connectors .................................... 3.5 mm stereo jack (2 channel), unbalanced;
tip (L), ring (R), sleeve (ground)
Impedance .................................... 10 kohms, DC coupled
Maximum level ............................ +8.5dBu
Audio output — buffered to RGB 320
Number/signal type ................... 1 buffered, stereo (2 channel), balanced/
unbalanced
Connectors .................................... 1 3.5 mm captive screw terminal, 10 pole
Impedance .................................... 50 ohms unbalanced, 100 ohms balanced
Gain error ...................................... ±0.1dB channel to channel
Drive (into RGB 320 audio input) .. > +16dBu, balanced at stated %THD+N
0dBu = 0.775 volts (RMS).
General
Power ............................................. ±8VDC, supplied via RGB 320
Temperature/humidity .............. Storage -40° to +158°F (-40° to +70°C) /
10% to 90%, non-condensing
Operating +32° to +122°F (0° to +50°C) /
10% to 90%, non-condensing
Rack mount ................................... No, but wall- or furniture-mountable
Enclosure type .............................. Metal
Enclosure dimensions
RGB 324/326
Plate ............................... 4.5" H x 4.5" W (11.43 cm H x 11.43 cm W)
Circuit board on plate .. 2.8" H x 3.5" W x 1.3" D
7.1 cm H x 8.9 cm W x 3.3 cm D
Box ................................. 3.75" H x 3.65" W x 3.5" D (2-gang)
9.5 cm H x 9.27 cm W x 8.9 cm D (2-gang)
RGB 340 ............................. 1.25" H x 5.7" W x 4.5" D
(width including flanges = 6.95”)
3.18 cm H x 14.5 cm W x 11.4 cm D
(width including flanges = 17.65 cm)
Shipping weight ........................... RGB 324/326 ............ 3 lbs (1.4 kg)
RGB 340 ..................... 2 lbs (0.9 kg)
