TP T 15HD 45 and TP T A 45 • Introduction
Introduction
1-2
Introduction
The Extron TP T 15HD 45 twisted pair transmitter and the
matching TP T A 45 audio input module provide a system for
sending RGBHV, RGBS, RGsB, component, composite, or
S-video and stereo audio signals over an Extron Skew-Free ™
A/V UTP or CAT 5/5e/6 UTP cable to a compatible TP or VTR
receiver. An external 12 VDC power supply provides power to
both the TP T 15HD 45 and the TP T A 45.
The TP T A 45 inputs unbalanced audio through a 3.5 mm stereo
phono jack and outputs digital audio to the TP T 15HD 45
transmitter.
The following table specifies the maximum recommended
transmission distances between the TP T 15HD 45 transmitter
and compatible Extron receivers at 60 Hz.
The maximum recommended distances for high quality (HQ)
and variable quality (VQ) transmissions are shown in the
table below.
Video
format and
resolution
Recommended
maximum range
to VTR Series
and
TP R 15HD A
Recommended
maximum range
to all other
Extron receivers
HQ VQ HQ VQ
Composite* 700 feet 800 feet 1000 feet 1050 feet
S-video* 700 feet 800 feet 1000 feet 1050 feet
Component* 700 feet 800 feet 1000 feet 1050 feet
640 x 480 500 feet 550 feet 1000 feet 1050 feet
800 x 600 400 feet 450 feet 800 feet 900 feet
1024 x 768 300 feet 400 feet 600 feet 700 feet
1280 x 960 300 feet 350 feet 450 feet 600 feet
1280 x 1024 250 feet 300 feet 400 feet 500 feet
1360 x 765 250 feet 300 feet 400 feet 500 feet
1365 x 768 250 feet 300 feet 400 feet 500 feet
1366 x 768 250 feet 300 feet 400 feet 500 feet
1440 x 900 250 feet 300 feet 350 feet 450 feet
1400 x 1050 250 feet 300 feet 350 feet 450 feet
1600 x 1200 200 feet 250 feet 300 feet 400 feet
1920 x 1200 200 feet 250 feet 300 feet 400 feet
