Extron • RGB 202xi Series • User’s Manual
2
Chapter Two
Rear Panel Connections
Computer-Video Inputs 1 and 2
Remote Switch
MBC Power
Audio Input and Output
BNC Outputs
Sync Options
RGB 202xi, RGB 202 VTG,
RGB 202 VS2 and RGB 202 VS SL2
User’s Manual
Extron • RGB 202xi Series • User’s Manual
Related Parts and Accessories
Page A-3
Monitor Breakout Cables
Extron MBC “Monitor Breakout Cables” feature monitor
loop-through connector for providing local monitor
viewing. Below is a sample listing of Extron’s most
popular MBC and ICWK cables for use with the
RGB 202
xi interface. Because this is only a partial listing,
please call Extron for any assistance to interface a
computer that may not be listed.
Part #
Cable Name
Hor. kHz
Ver. Hz
26-108-03
MBC AMIGA HR
15.7
60
26-198-01
MBC Apollo Mono
64.0
60-76
26-018-02
MBC Apple IIGS
15.7
60
26-064-01
MBC Burroughs Color
22.2
60
26-307-01
MBC Cornerstone DP120
104
60
26-176-01
DEC VR Terminals
54 - 69
60
26-262-01
MBC E/Machine Mono
35.61
68
503-066
MBC IBM 3151
27.2
67.5
26-003-01
MBC IBM 3161/63/91/96 Mono
27.0
64.8
26-148-01
MBC IBM 3162
25.9
54.8
26-043-01
MBC IBM 3164/79/92/97 Color
22.31
60
26-227-01
MBC IBM 3178C
15.4
70
26-043-02
MBC IBM 3192 Mono
36.0
60
26-100-01
MBC IBM 3193C
50.6
80
26-058-01
MBC IBM 3194 14" Display
29.6
73
26-109-01
MBC IBM 3194 Mono
29.0
73
26-009-01
MBC IBM 3270PC
23.6
63
70-009-01
MBC IBM 3472/3477 Infowindow Kit
26.37
60
26-055-01
MBC IBM PC Mono (MDA)
18.1
50
26-010-01
MBC IBM PCC (CGA/EGA)
15.7-22
60
26-005-02
MBC IBM PGA HR
31.5
60
26-117-01
MBC IBM PS/2 (Standard VGA Only)
35
60-70
26-162-01
MBC IBM VGA HR (Super VGA)
31.5-72
60-70
26-224-01
LBC IBM VGA HR (Laptop Cable)
31.5-37
60-70
26-176-01
PowerPC (IBM)
31 - 117
60 - 88
26-162-02
MBC IMAGE Adapter/A
31-61
60 or 70
26-018-02
MBC Mac/Quadra/PowerMac HR
35-68
68
26-251-01
MBC Memorex TELEX 1192
27.5
64.5
26-272-01
MBC NCD 14C/17C-CR/19C-G
56-82
70
70-012-01
MBC NCD 15B/16E/19R
58-82
70
26-220-01
MBC NeXt Buffer, Mono
63.0
68
26-283-01
NeXT Color
63
68
26-270-01
MBC RGB H&V (9 Pin to 5 BNC's)
Varies
26-213-01
MBC RGBS (9 Pin to 4 BNC’S)
Varies
26-018-01
RasterOps/SuperMac
35 - 64
66
26-198-01
MBC SUN/Apollo Mono
61-90
66-76
26-283-01
MBC Sun Sparc/SGI
61-89
66-70
503-072
ICWK DEC VT 320*
18.0
60
70-004-01
ICWK DEC 340 KIT
31.5
60
70-004-03
ICWK DEC VT 340
31.5
60
503-125
ICWK DEC VT 340 PLUS*
31.5
60
503-120
ICWK DEC VT 420*
37.0
60 or 70
503-071
ICWK HP 700/94*
28.6
60
26-029-01
ICWK IBM 3180
20.0
83
70-006-01
ICWK IBM 3476
28.0
60
70-009-01
IBM 3472/3477 Infowindow kit
26.37
60
26-102-03
ICWK MAC Classic RGB (9 pin)
22.2
60
26-026-01
ICWK MAC RGB (9 pin)
22.2
60
26-102-02
ICWK MAC SE RGB (9 pin)
22.2
60
503-085
ICWK Memorex/TELEX 1191*
27.5
65.7
26-043-03
ICWK Memorex C19A
27.5
62.7
26-096-01
ICWK Wsye 50
23.0
60
