Extron • RGB 202xi Series • User’s Manual
Introduction • Features and Specifications
Page 1-5
Specifications
Input Signal
Video:
Analog 0.3 to 1.45 V p-p
ECL
0.3 to 1.45 V p-p
TTL
2.7 to 7.00 V p-p
Audio:
Connector: 2.5 mm Stereo Jack
Impedance: High Z
Sync:
Separate Sync TTL/Analog
Horizontal Sync - Pos,/Neg.
Vertical Sync - Positive/Negative
Composite Sync TTL/Analog Level
Positive/Negative
Composite Sync on Green Video
0.3V p-p Negative
(video 0.7V p-p positive)
Output Signal
Video:
Analog .5 to 1.2V p-p
Sync:
Auto Sync on Green
Composite Sync
(TTL level, 4V p-p)
(separate, negative-going)
Separate H and V Sync
(TTL level, 4v p-p)
Tracks polarity
(or force negative sync via jumper)
Audio:
Connector: (2) 2.5 Stereo Jacks
Impedance: 600 ohms
Level: Line
RGB Video Output (RGB 202 VTG model)
RGB Video
1 v p-p
Peak White
0.7 - 0.714 v p-p above ground
Sync
0.272 - 0.375 v p-p below ground
Frequency Range
Horizontal:
15.5 kHz to 150 kHz
(Automatically)
Vertical:
40 Hz to 140 Hz
(Automatically)
LCD Scan-Rate Range
10 to 150 kHz Horizontal
30 to 200 Hz Vertical
RGB Video Bandwidth
300 MHz (-3dB) Bandwidth
Operating Temperature
Operating
0
o
to 50
o
C (31
o
to 122
o
F)
Storage
-20
o
to 60
o
C (-4
o
to 140
o
F)
