Mlc 206 backlight replacement guide, cont’d, Mlc 206 • backlight replacement guide 2 – Extron Electronics MLC 206 Backlight Replacement Guide User Manual
Page 2
MLC 206 Backlight Replacement Guide, cont’d
MLC 206 • Backlight Replacement Guide
2
5.
Lift off the transparent, rectangular labels; save them for later use. You may
need a small, flat bladed screwdriver to gently pry the labels out.
Note which labels were in which window so you can put them back in the same
locations during reassembly.
VCR
DVD
Extr
on
Medi
aL
ink
C
on
trol
ler
ML
C 20
6
DISPLAY
POWER
VOLUME
MAX/
MIN
Window Labels
Remove four screws.
Plastic Window
Faceplate
MLC 206 with
Electroluminescent
Backlight Circuit Board
(part #20-440-01)
DVCAM
Preset 1
Menu
Laptop 2
Laptop 1
DVD
Extr
on
Medi
aLi
nk
C
on
tro
lle
r
ML
C 20
6
DISPLAY
POWER
VOLUME
MAX/
MIN
Plastic Window
Window Label
Faceplate
Remove four screws.
MLC 206
with
LED Backlight
Circuit Board
(part #20-497-01)
