Metal Decora Mounting Brackets • Installation Guide
Mounting Bracket Templates
2.45" (6.22 cm)
4.28"
(10.87 cm)
Recommended
cut-out area
for the installation
surface.
Top Panel
1.94" (4.93 cm)
3.80"
(9.65 cm)
SURFACE
CUT-OUT AREA
FOR WALL MOUNT
Template for the 1-gang
mounting bracket
4.26" (10.83 cm)
4.28"
(10.87 cm)
Recommended
cut-out area
for the installation
surface.
Top Panel
SURFACE
CUT-OUT AREA
FOR WALL MOUNT
3.75" (9.53 cm)
3.80"
(9.65 cm)
Template for the 2-gang
mounting bracket
TEMPLATES ARE NOT FULL SIZE.
