MMX 32 VGA MTP • Introduction
2
Features
•
Inputs — The MMX VGA MTP has three female 15-pin HD input connectors, each with
a 3.5 mm stereo jack.
•
Outputs — The unit routes computer video and audio signals to two outputs:
•
Output 1 is a local output, using one female 15-pin HD connector with a 3.5 mm
stereo jack.
•
Output 2 is a transmitted output, using an RJ-45 UTP connector for RGBHV video
and summed audio, with an additional audio output on a 5-pole captive screw
connector.
•
Stereo audio — The unbalanced stereo audio input can be output as either balanced or
unbalanced stereo audio, or it can be output as dual mono audio.
•
Bandwidth — The switcher features 300 MHz (-3 dB) bandwidth to accommodate any
signal resolution.
•
Peaking option — To compensate for signal loss due to long distance transmission, the
MMX 32 VGA MTP offers DIP switch selectable peaking capability.
•
Bi-level/tri-level sync — Output 2 is compatible with virtually any sync signal. Bi-level
or tri-level sync transmission is DIP switch selectable.
•
Front panel control — Each output has a set of input selector buttons and LEDs for
easy input selection.
•
Remote control — Operate the switcher via optional contact closure and RS-232
remote controllers.
•
Portability — The switcher is light and compact, with rubber feet for tabletop
operation.
•
Rack and furniture mounting — The MMX 32 VGA MTP can be mounted on a rack
shelf or under a desk or podium.
•
Power — An external 12 VDC power connector is included with the switcher.
•
Optional accessory compatibility — The MMX 32 VGA MTP is compatible with
MMX 32 AAP and MMX 32 MAAP contact closure panels. See the application diagram
(
) on page 23.
•
Additional accessories — Extron twisted pair receivers—MTP U series and
MTP RL 15HD A (sold separately)—are required for use with the MMX 32 VGA MTP for
output 2. See the application diagram (
) on page 1.
