MMX 32 VGA MTP • Remote Control 15
Command ASCII Command
(host to switcher)
Response
(switcher to host)
Additional description
Front panel security lock out
Lock front panel 1 X/x Exe1] Lock front panel.
Unlock front panel 0 X/x Exe0] Unlock front panel.
Lock status X/x X(] Show lock status (0 = unlocked and 1 = locked)
Reset to factory defaults
System reset (factory default) EZXXX} Zpx] Clear all ties and unmute audio and video.
Unmute RGB EZZ} Zpz] Unmute all.
View ties and output mute
View RGB output tie
Example: X#%
2% X@]
3]
Output 2 video is tied to input 3 video.
View audio output tie
Example: X#$
1$ X@]
2]
Output 1 audio is tied to input 2 audio.
Output mute X#VM
“VM” must be upper case
X2)] Output mute X2) (0 = no mute, 1 = video
mute, 2 = audio mute, 3 = video and audio
mute).
Information requests
Information request
Example:
I/i
i
See note below for
explanation
V1*X@•A1*X@•V2*X@•A2*X@•Vmt1*X(•Amt1*X(•Vmt2*X(•Amt2
*X(]
V1*1•A1*1•V2*2•A2*2•Vmt1*0•Amt1*0•Vmt2*0•Amt2*0
Request part number N/n xx-xxx-xx] 60-565-01 = MMX 32 VGA MTP switcher.
Query firmware version Q/q X1(] Show firmware version number.
NOTES: X@ = Input number (for tie) 0 – 3
0 = disconnected
X# = Output number 1 or 2
X( = Lock status 0 = unlocked
1 = locked
X1( = Controller software version number to second decimal place
X2) = Mute 0 = no mute 2 = audio mute
1 = video mute 3 = video and audio mute
a
Input 1 supplies video and audio for output 1.
b
Input 2 supplies video and audio for output 2.
c
Output 1 does not mute video or audio.
d
Output 2 does not mute video or audio.
a b c d
