IN2013HR Operation Manual - V1.0 12/05/00

6. Connect the Local Computer Monitor - (if present) to the IN2013HR local monitor output

port. Check the Monitor Emulation Dipswitch Settings on the bottom of the IN2013HR.

•

When Using a Local Monitor - make sure that all dipswitches in the box labeled
MONITOR EMULATION are set to “0”.

•

If No Local Monitor is Required - using the IN9339 alignment tool (provided), gently
set the monitor emulation dipswitches according to the Monitor Emulation Dipswitch
Chart provided on page 9.

Check the Monitor Emulation chart and dipswitch settings carefully. Any
improper setting of the emulation dipswitches may lead to improper
operation and could even result in severe damage to the computer video
port or the monitor. If you are in doubt as to which monitor emulation to
choose, set all the Monitor Emulation dipswitches to “0” and connect the
local monitor.

6. Apply Power - to the IN2013HR using the IN9230 IEC power cable (included).

7. Turn On - the computer, the IN2013HR, the local monitor (if applicable) and the display

device. If necessary, adjust the gain, sharpness and / or horizontal position control as
detailed on pages 6 and 7.
