10
IN2013HR Operation Manual - V1.0 12/05/00 ©2000 - INLINE, Inc.
Specifications
IN2013HR Computer Video Interface
Input
Connector type (1) 13W3 male
RGB Video Signals Analog, 0.7 Vp-p Nominal
Input Impedance 75 Ohms
Sync Signals TTL compatible
Horizontal Scan Range 15 KHz - 135.0 KHz
Vertical Scan Range 50 Hz - 120 Hz
Local Monitor Output
Connector Type
(1) 13W3 female connector, buffered output,
sync format same as input
Data Display Outputs
Connector Type 2 Sets of (5) BNC female
Output Signal Formats RGsB, RGBS, RGBHV, Composite Monochrome
RGB Signals Analog Video, 75 ohm impedance
Bandwidth 230 MHz @ -3 dB
Rise and Fall Times 1.5 nano seconds
Video Gain (Terminated) Variable Control - Adjustable from .7 (30% voltage
decrease) to 1.3 (30% voltage increase)
Sync Signal
H, V and S: 5V unterminated and 2Vp-p 75 ohm terminated
Sync on Green: 0.3 Vp-p 75 Ohm terminated
Horizontal Pulse Width
30 KHz - 40 KHz: 1.5
µ
Sec
> 40 KHz: 0.7
µ
Sec
Vertical Pulse Width
Same as the input for H & V,
§ µ
Sec for Sync on Green or Composite Sync
Controls
External
Horizontal Position, Video Gain, Sharpness,
Output Sync, Input Computer Select, Monitor Emulation
Dimensions
Size 1.75" x 11.75" x 6.5" / 4.4cm x 29.9cm x 16.5cm
Product Weight 2 lb. / 1kg.
Shipping Weight 5 lb. / 2.5kg.
Power
Power Supply Internal Switch Mode: 90 - 260 VAC; 0.29A; 47 - 63 Hz
Power Consumption 14.5 Watts
Regulatory Compliance
Safety & EMI UL 1950, CAN/CSA-22.2 No. 950 3 rd Ed.
FCC class A; CE: EN50022 (1987), EN50081-1 (1991),
EN50082-1 (1992 & 1994), EN60950-92
