Product Overview
DESCRIPTION
The IN2112R is a high-performance computer video interface for analog video signals including VGA,
SVGA, XGA, MAC, Sun and other high-resolution workstations. The IN2112R combines high-resolution
computer interfacing with two inputs, modular A/V connector plates and front panel A/C power outputs into
a 2U rack mountable unit. This highly integrated approach gives audiovisual professionals the ability to
quickly design and install functional, customized computer interfacing and A/V connectivity solutions for a
broad spectrum of applications.
Like other INLINE interfaces, the IN2112R performs the following functions:
•
Signal Splitting - allows the simultaneous connection and viewing of both the computer’s local monitor
and a second output device such as an LCD data projector or a presentation monitor.
•
Physical Interfacing - Because computers employ many different types of video output connectors, it is
sometimes difficult to directly connect them to data projection devices. The IN2112R simplifies
interfacing, routing and switching tasks by acting as a universal adapter. Through the use of removable
input cables, the IN2112R can be attached to different computers and will provide a video output signal
on five BNC connectors. The output signal may be set to RGBHV (default), RGBS or RGsB formats.
The IN2112R is not a scan converter. The data projector, monitor or other output device
must be compatible with the horizontal scan rate output by the computer video card.
PRODUCT FEATURES
Rack Mountable Unit - Featuring integral rack mounting ears, the IN2112R is specifically designed to
mount in a standard 19’ equipment rack in a 2U space; no additional rack shelves or rack ears are required.
The interface has a sleek black finish that blends well with other rack mounted equipment, complementing
the decor of boardrooms, training facilities, control rooms and other high-tech / high profile installations
featuring exposed equipment racks.
Two Input Switcher - Users may select Input 1 or Input 2 using a front panel switch. Front panel LEDs
illuminate to indicate the current input. In Autoswitch mode, the interface senses which input has an active
signal and switches automatically. If both inputs are active, Input 2 has priority. Input 1 or 2 may be
selected remotely via contact closure.
Modular Faceplate - Ca p able of holding up to eight A/V connector plates, the IN2112R can
accommodate the exact connectors required for each installation. Dozens of engraved connector plates are
available for audio, video, computer, data and phone connections. INLINE can provide custom engraving
services to label the connector plates as required for various applications (additional charge for custom
engraving). Available A/V modules are listed on pages 12-13.
