14
IN2112R OPERATION MANUAL - PRELIMINARY 8/23/99 ©1999 - INLINE, INC.
Specifications
Input
Connector Type (2) 15-pin HD male - standard VGA pin-outs
RGB Video Signals Analog, 1.5 Vp-p max.
Input Impedance 75 ohm
Sync Signals TTL compatible
Horizontal Scan Rate 30 KHz - 130 KHz
Vertical Sync Range 30 Hz - 120 Hz
Stereo Audio Connector (2) 3.5mm stereo mini female - Impedance: 10 Kohm
Output
Local Monitor (Buffered) (2) 15-pin HD female - standard VGA pin-outs
Main Output (5) female BNC connectors
Output Signal Formats
RGBHV - Negative sync polarities (default)
RGBHV - Mirror input sync polarities, RGBS or RGsB
RGB Signals Analog Video, 75 ohm impedance
Bandwidth 400 MHz @ -3 dB with .7 volt input signal
Rise and Fall Times 0.875 nano seconds
Gain 1.0 +/- 5% (unity)
Sync Signal
H, V and S: 4V Unterminated; 2V when 75 ohm terminated
Gs: 0.3V when 75 ohm terminated
Horizontal Pulse Width Horizontal Position Enabled: Approximately 1.5 usec
Horizontal Position Deleted: Approximately the same
as the input signal
Vertical Pulse Width Approximately the same as the input signal
Local Audio Outputs (2) 3.5mm stereo mini female for Unbalanced Audio
Stereo Audio Output (Passive)
5-pin mini Phoenix captive screw terminal
for balanced or unbalanced audio; Impedance: 50 ohm
Controls
External
Horizontal Position Control
Input Selector
Internal
10 Dip Switches
Audio Output Unbalanced / Balanced (4 jumpers)
Dimensions
Size (including faceplate) 3.5” H x 19” W x 5.5” D / 8.9cm x 48.3cm x 14.0cm
Shipping Weight 6 lbs. / 3 kg.
Power
Power Supply Internal Universal: 90 - 240VAC; 47 - 63Hz
Front Panel A/C Outlets
600 Watts Total
IN2112R: (2) Edison female
IN2112R-IEC: (2) IEC female
IN2112R-EU: (2) Euro female
Regulatory Compliance
Safety UL 1950, CAN/CSA-22.2 No. 950 3 rd Ed.
EMI
FCC class A; CE: EN50022 (1987), EN50081-1 (1991),
EN50082-1 (1992 & 1994), EN60950-92
