Chapter two – Extron Electronics IR Link User Manual
Page 5
IR Link • Introduction
Introduction
IR Link
2
Chapter Two
Installation and Operation
Installation Overview
UL Requirements
Rear Panel Connectors and Cabling
Front Panel Features and Operation
Testing/Troubleshooting
About the IR Link
The Extron IR Link is a one-gang size, hardwired, infrared
signal repeater that can be used with any Extron product that
uses 38 kHz carrier frequency IR signals. Infrared signals
received by the IR Link are passed on to the Extron device,
which can be installed out of the direct line of sight of the IR
remote controls.
Features
Grey, black, or white faceplates
— The IR Link is offered in
three shades for integration into a variety of
environments.
Furniture and wall mountability
— The IR Link can be
mounted onto or in furniture or walls either directly or
attached to a standard electrical wall box or mud ring.
1-2
