Command ASCII
Command
(host to ISM)
Response
(ISM to host)
Additional Description
Output scaler rate
Set output rate X@ * X2!* X2@= RteX@ *X2!*X2@] Set resolution/refresh rate.
View X@= X2! *X2@] View selected output rate.
Start auto image
Start auto image 14*X@# ImgX@] Auto image input tied to X@ .
Auto memory
On X@*1M X@Aut1] Set auto memory to on.
Off X@*0M X@Aut0] Set auto memory to off.
View setting X@M X1)] View current auto memory.
Auto image
Enable 55*X@* X!*1# X@ ImgX!*1] Enables auto image for all
inputs.
Disable 55*X@* X!*0# X@ ImgX!*0] Disables auto image.
View 55*X@* X!# X1)] View auto image setting.
Input aspect ratio
16:9 9*X@*1# X@ AspX!*1] Set input aspect ratio to 16:9.
4:3 9*X@*0# X@ AspX!*0] Set input aspect ratio to 4:3.
View 9*X@# X5%] View current aspect ratio.
Full screen
Enable 99*X@*X!*1# X@ FulX!*1] Enables full screen view.
Disable 99*X@*X!*0# X@ FulX!*0] Disables full screen view.
View 99*X@*X!# X1)] View the current on/off status.
Test pattern
On X@ *X2) J X@ TstX2)] Select test pattern.
View X@ J X2)] View the test pattern selected.
NOTE: X! = Input number, 0-8
X@ = Output number, 1-8
X1) = Mode status, 1 = on, 0 = off
X2) = Test pattern, 00 = off, 01 = color bars, 02 = 4:3/16:9 crosshatch, 03 = 4x4 crosshatch,
04 = split gray scale, 05 = ramp, 06 = alternating pixels, 07 = crop, 08 = 1.33 aspect,
09 = 1.78 aspect, 10 = 1.85 aspect, 11 = 2.35 aspect
X2! = Output resolution, 17 = 720p, 18 = 1080i, 19 = 1080p
X2@ = Refresh rate, 1 = 50 Hz, 2 = 60 Hz, 7 = 24 Hz, 8 = 25 Hz, 9 = 30 Hz, 10 = 59.94 Hz
X5% = Aspect ratio, 1 = 16:9, 0 = 4:3
ISM HDSDI Output Board • Setup Guide, cont’d
