SPECIFICATIONS

Input

Connector type

15 Pin HD male

RGB Video Signals

Analog, 0.7 Vp-p Nominal

Input Impedance

75 Ohms

Sync Signals

TTL compatible

Horizontal Scan Range

15.0 KHz - 135.0 KHz

Vertical Scan Range

30 Hz - 180 Hz

Output

Connector Type

5 BNC Female connectors

Output Signal Formats

RGBHV (Default), RGBS or RGsB,

RGB Signals

Analog Video, 75 ohm impedance

Bandwidth

400 MHz @ -3 dB

Rise and Fall Times

0.875 nano seconds

Gain

1.0

Sync Signal

H, V and S: 5V unterminated and 2Vp-p 75 ohm terminated

Gs: 0.3 Vp-p 75 Ohm terminated

Horizontal Pulse Width

Horizontal Position Enabled: approximately 1.5

sec

Horizontal Position Disabled: Approximately the same

as the input signal

Vertical Pulse Width

Approximately the same as the input signal

Controls

External

Horizontal Position Control

Dip Switches

Internal

Untermination jumpers for red, green and blue

Dimensions

Size

1.25" H x 5" W x 4" D

Shipping Weight

3 lb.

Power

Power Supply

IN9204-X: External AC to DC Power Transformer, 9V 500 mA

Regulatory Compliance

Safety

UL 1950, 3

Ed.; CE: EN60950-92;

CAN/CSA-22.2 No. 950 3

Ed.

EMI

FCC class A; CE: EN50081-1,

EN55022, EN50082-1

Optional Accessories

IN8000 Series VGA Cable: Available in a variety of lengths from 3’ to 100’
IN7000-5 Series RGBHV Cable: Standard 5 - BNC Cable available in a variety of lengths from 6' to 250'
IN7100-5 Series RGBHV Cable: High Resolution 5 - BNC Cable, available in lengths from 6' to 250'
IN7200-5 Series RGBHV Cable: Ultra High Resolution 5 - BNC Cable, available in lengths from 6' to 250'
