GLI 350 and ADA 2/GLI 350 HV
Installation
6
Return loss .................................... <-45 dB @ 5 MHz
DC offset ....................................... ±10mV maximum
Sync
Input type ..................................... RGBHV, RGBS, RGsB, RsGsBs
Output type .................................. RGBHV, RGBS, RGsB, RsGsBs
Input level ..................................... RGBHV, RGBS (min./max.): 0.5 V to 5
Vp-p (analog/TTL)
RGsB (nominal): 0.3 Vp-p (analog)
Output level .................................. TTL: 5 Vp-p, unterminated
Input impedance .......................... 510 ohms
Output impedance ....................... 75 ohms
Max. propagation delay .............. H: 60 ns
Max. rise/fall time ....................... 4 ns
Polarity .......................................... Positive or negative
General
External power supply (attached)
........................................................ 100 VAC to 240 VAC, 50/60 Hz, external,
autoswitchable; to 9 VDC, 1 A, regulated
Temperature/humidity .............. Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Rack mount .................................. No
Enclosure type .............................. Metal
Enclosure dimensions ................. 1.75" H x 4.6" W x 4.7" D (1U high, quarter
rack wide)
4.4 cm H x 11.7 cm W x 11.9 cm D
Product weight ............................. 1.8 lbs (0.8 kg)
Shipping weight ........................... 4 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Transit Association)
Listings .......................................... UL, CUL
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
