GLI 350 and ADA 2/GLI 350 HV
Specifications, cont’d
Specifications — ADA 2/GLI 350 HV
Video
Gain ................................................ Unity
Bandwidth ..................................... 350 MHz (-3 dB), fully loaded
CMRR
......................................................... >47 dB @ 60 Hz, >30 dB @ 10 MHz
Video input
Number/signal type ................... 1 RGBHV, RGBS, RGsB, RsGsBs,
component video, S-video, composite
video
Connectors ................................... 5 BNC female
Nominal level ............................... 0.7 Vp-p for RGB
Minimum/maximum levels ....... Analog: 0.3 V to 1.5 Vp-p with no offset at
unity gain
Impedance .................................... 75 ohms
Horizontal frequency .................. 15 kHz to 135 kHz
Vertical frequency ....................... 30 Hz to 150 Hz
Return loss .................................... <-39 dB @ 5 MHz
Video output
Number/signal type ................... 2 RGBHV, RGBS, RGsB, RsGsBs,
component video, S-video, composite
video
Connectors ................................... 2 x 5 BNC female
Nominal level ............................... 0.7 Vp-p for RGB
Minimum/maximum levels ....... Analog: 0.3 V to 1.5 Vp-p
Impedance .................................... 75 ohms
Product weight ............................. 1.9 lbs (0.9 kg)
Shipping weight ........................... 4 lbs (2 kg)
Vibration ....................................... ISTA 1A in carton (International Safe
Transit Association)
Compliances ................................. CE
MTBF ............................................. 30,000 hours
Warranty ....................................... 3 years parts and labor
All nominal levels are at ±10%.
