GLI 2000 Series • Specifications 5
Video
Gain ................................................... Unity
Core saturation voltage .................. >10V
See the Extron Web site for details on core saturation test
conditions.
Bandwidth
GLI 2000 5BNC ................... >425 MHz (-3dB) for RGB, >200 MHz
(-3dB) for HV
GLI 2000 2BNC ................... >100 MHz (-3dB)
CMRR
GLI 2000 5BNC ................... >58dB @ 50 Hz or 60 Hz
GLI 2000 2BNC ................... >53dB @ 50 Hz or 60 Hz
Video input
Number/signal type
GLI 2000 5BNC ................... RGBHV, RGBS, RGsB, RsGsBs
GLI 2000 2BNC ................... 1 S-video or 2 composite video
Connectors
GLI 2000 5BNC ................... 5 female BNC
GLI 2000 2BNC ................... 2 female BNC
Nominal level .................................. 1V p-p for Y of S-video, and for composite
video
0.7V p-p for RGB
0.3V p-p for C of S-video
Minimum/maximum levels ......... Analog: -15V to +15V p-p with no offset
Impedance ........................................ 75 ohms
Horizontal frequency ..................... 10 kHz to 2000 kHz
Vertical frequency ........................... 15 Hz to 180 Hz
Return loss
GLI 2000 5BNC ................... <-27dB @ 1 MHz to 100 MHz
GLI 2000 2BNC ................... <-28dB @ 1 MHz to 100 MHz
Video output
GLI 2000 5BNC ................... RGBHV, RGBS, RGsB, RsGsBs
GLI 2000 2BNC ................... 1 S-video or 2 composite video
Connectors
GLI 2000 5BNC ................... 5 female BNC
GLI 2000 2BNC ................... 2 female BNC
Specifications
