Extron Electronics GLI 2000 2BNC User Manual
Page 5
The H and V channels on the GLI 2000 5BNC have a
bandwidth of 200 MHz, rather than 425 MHz, and should
not be used for high-resolution signals.
GLI 2000 2BNC
IN
IN
GLI 2000 2BNC
GROUND LOOP INHIBITOR
OUT
OUT
VIDEO/Y
VIDEO/C
1
2
GLI 2000 2NBC connectors
1
Input connectors
— Connect an S-video source or two
composite video sources to these two female BNC
connectors.
2
Output connectors
— Connect an S-video display or two
composite video displays to these two female BNC
connectors.
GLI 2000 Series • Installation
