Features
z
Ultra high performance — Outputs up to eight perfect, pixel-by-pixel RGBHV or
digital video transmissions to compatible receivers. The FOX DA8 can handle analog
video resolutions up to 1600x1200 at 60 Hz. Higher resolutions can be transmitted, but
with some loss of video quality.
z
Optical input and outputs — The FOX DA8 inputs and outputs the optical signal on
LC video connectors.
z
Active and individually isolated outputs — The FOX DA8 uses active signal splitting
to maintain equal transmitter power to all outputs, maximizing distance capabilities by
ensuring full availability of optical loss budget for each output.
z
System video output — When the optical input is from a FOX 500 or FOXBOX Tx
(rather than a FOX HD-SDI), the video portion of the optical video output can be
decoded to either RGB video or DVI video, depending on the receiver connected.
z
Rack mounting — The unit is rack mountable in any conventional 19 inch wide rack,
using an Extron full size rack shelf.
z
Power — The 100 VAC to 240 VAC, internal power supply provides worldwide power
compatibility
