Reference
Information
This section discusses the specifications, part numbers, and accessories for the
DTP HDMI 301 Tx/Rx transmitter and receiver. Topics that are covered include:
• Specifications
• Part Numbers and Accessories
• Mounting the Transmitter or Receiver
Specifications
NOTES : • This product consists of a transmitter (DTP HDMI 301 Tx) and a receiver (DTP HDMI 301 Rx), sold
separately, with twisted pair cables linking the transmitter and receiver.
• *Appropriate HDMI to DVI-DI cables or adapters are required for DVI signal input/output .
Video
Maximum data rate ........................ 6.75 Gbps (2.25 Gbps per color)
Maximum pixel clock ...................... 165 MHz
Resolution range ............................ Up to 1920x1200 or 1080p @ 60 Hz; 8, 10, or 12 bit color depth
Formats .......................................... RGB and YCbCr digital video
Standards ....................................... DVI 1.0, HDMI 1.3
Video input — transmitter
Number/signal type ........................ 1 single link HDMI (or DVI-D*)
Connectors .................................... 1 female HDMI type A
Interconnection between transmitter and receiver
Connectors .................................... 2 female RJ-45 per unit for 2 cables connecting the transmitter and receiver
TP1 output transmits digital video, embedded digital audio, RS-232, IR, and
remote power.
TP2 output transmits analog stereo audio.
Termination standards .................... TIA/EIA T568A or T568B
Signal transmission distance ........... 330' (100 m) using CAT 5e/6 UTP or STP cable
Video output — receiver
Number/signal type ........................ 1 single link HDMI (or DVI-D*)
Connectors .................................... 1 female HDMI type A
Audio
Gain ............................................... Unbalanced output: 0 dB; balanced output +6 dB
Frequency response ........................ 20 Hz to 20 kHz, ±0.05 dB
THD + Noise ................................... 0.03% @ 20 Hz to 20 kHz at maximum output
S/N ................................................. >90 dB, at maximum output (15 dBu), balanced (unweighted)
Stereo channel separation .............. >80 dB @ 1 kHz to 20 kHz
DTP HDMI 301 • Reference Information 12
