CD 900 Decoder • Setup and Operation
Setup and Operation, cont’d
CD 900 Decoder
To output component video
1 . Set the RGB/component DIP switch to the off/left
position.
2 . Set the H/HV/SOG switch to the SOG position.
Troubleshooting
If the image does not appear
1 . Ensure that all devices are plugged in and powered on.
The CD 900 is receiving power if the front panel power
LED is lit.
2 . Ensure an active input is selected on the CD 900.
3 . Ensure the RGB/Component DIP switch and the
H/HV/SOG switch are in the correct positions for the
video output. See “Setting Up the CD 900/Rear Panel
Controls” on page 3-2 for more details.
4 . Ensure the horizontal and vertical sync DIP switches are in
the correct position. See “Setting Up the CD 900/Rear
Panel Controls” on page 3-2 for more details.
5 . Check the cabling and make corrections as necessary.
6 . Call the Extron customer support hotline if necessary.
If the image is not displayed correctly
1 . If the picture bends or flags at the top of the screen, change
the position of the serration pulse DIP switch.
2 . If the output image looks too green, the CD 900 may be set
to sync on green (the H/HV/SOG switch set to SOG).
3 . If the picture hangs off the edge of the screen, adjust the
H Shift control.
4 . Readjust the picture controls after replacing a video
source.
5 . If the image still does not display properly, call the Extron
customer support hotline.
If the image does not respond to picture controls
1 . The CD 900 is in executive mode. Set Executive Mode DIP
switch to the right.
4
Chapter Four
Remote Control
Simple Instruction Set Control
Windows-Based Program Control
Contact Closure Control
3-6
